Impact Wrench NWH-320P
[Features]
· Clutch hammer type: using a clutch hammer with high striking power, enables powerful tightening and smooth removal.
· Anvil P Type
· Clutch hammer type: using a clutch hammer with high striking power, enables powerful tightening and smooth removal.
· Anvil P Type
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
20183
Basic information
| Max. Tightening Torque(N▪m) | 1800 | Socket Plug Angle(mm) | 25.4 | Capacity Bolt Diameter(φ/mm) | Standard: 39/high power 24 |
|---|---|---|---|---|---|
| Number Of Rotations(rpm) | 4000 | Operating Air Pressure(Mpa) | 0.6 | Air Consumption Amount(m³/min) | 0.5 |
| Ventilation | Side | Detailed Model Number | NWH-320P | Overall Length(mm) | 276 |
| Weight(g) | 9750 | Hose B Diameter Fixing Screw | Rc3/8 | Hose I.D.(mm) | 12.7 |
This page is Impact Wrench NWH-320P, part number 20183.
You can find the detail information about specifications and dimensions on part number 20183.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
