Leading Drills, FX-LDS

Leading Drills, FX-LDS

Provides high speed and long tool life in centering as well as chamfering.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
FX-LDS-16X90
FX-LDS-20X90
FX-LDS-25X90
Part NumberStandard Unit PriceVolume DiscountShipping Days?Tool Diameter (D)
(mm)
Tool No. Shank diameter (d)
(mm)
Overall Length
(mm)
Groove Length
(mm)
Minimum Pilot Hole Diameter
(mm)

357.80 €

Quote 16856151616118415

627.80 €

4 Days 20856152020132465

936.40 €

5 Days 25856152525151535

Loading...

  1. 1

Basic information

Application Centering (Positioning) / Hole Chamfer Tip angle (θ) 90 work material General steel / Quenched and tempered steel / High hardness steel / Cast Iron / Aluminum / Titanium / Copper
Single blade, two blades Single blade Peripheral Blade Y/N NA Tool Material Type Carbide
Coating Y/N Available Coating Type TiAlN
