2-Flute, Short, DIA-EDS
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| DIA-EDS-0.5 |
| DIA-EDS-1 |
| DIA-EDS-1.5 |
| DIA-EDS-2 |
| DIA-EDS-3 |
| DIA-EDS-4 |
| DIA-EDS-5 |
| DIA-EDS-6 |
| DIA-EDS-8 |
| DIA-EDS-10 |
| DIA-EDS-12 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Blade diameter (D) (φ) | Blade length (ℓ) (mm) | Shank diameter (d) (mm) | Overall Length (L) (mm) | Tool No. | |
|---|---|---|---|---|---|---|---|---|---|
96.96 € | 1 | 6 Days | 0.5 | 1 | 4 | 40 | 8504601 | ||
92.08 € | 1 | 6 Days | 1 | 2.5 | 4 | 40 | 8504602 | ||
92.08 € | 1 | 6 Days | 1.5 | 4 | 4 | 40 | 8504603 | ||
92.08 € | 1 | 6 Days | 2 | 6 | 4 | 40 | 8504604 | ||
133.79 € | 1 | 6 Days | 3 | 8 | 6 | 45 | 8504606 | ||
135.96 € | 1 | 6 Days | 4 | 11 | 6 | 45 | 8504608 | ||
142.46 € | 1 | 6 Days | 5 | 13 | 6 | 50 | 8504610 | ||
142.46 € | 1 | 6 Days | 6 | 13 | 6 | 50 | 8504612 | ||
178.21 € | 1 | 6 Days | 8 | 19 | 8 | 60 | 8504616 | ||
243.75 € | 1 | 6 Days | 10 | 22 | 10 | 70 | 8504620 | ||
275.71 € | 1 | 6 Days | 12 | 26 | 12 | 75 | 8504622 |
Loading...
Basic information
| work material | Aluminum / Copper / Graphite / Resin | Number of flutes(sheet) | 2 | Type | Square |
|---|---|---|---|---|---|
| Coating | Diamond Coat | Machining Application | Flat Surface / Side Surface / Groove / Thrust (Z-Feed) / Inclined Cutting | Blade tip shape | With Lead |
| Torsion Angle (θ) | Standard Helix (30 to 40°) |
Configure
Basic Attributes
-
Blade diameter (D)(φ)
-
Blade length (ℓ)(mm)
-
Shank diameter (d)(mm)
-
Overall Length (L)(mm)
-
Tool No.
-
Type
- DIA-EDS
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
