2-Flute, Medium, MG-EDN
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| MG-EDN-3 |
| MG-EDN-3.5 |
| MG-EDN-4 |
| MG-EDN-4.5 |
| MG-EDN-5 |
| MG-EDN-5.5 |
| MG-EDN-6 |
| MG-EDN-6.5 |
| MG-EDN-7 |
| MG-EDN-7.5 |
| MG-EDN-8 |
| MG-EDN-8.5 |
| MG-EDN-9 |
| MG-EDN-9.5 |
| MG-EDN-10 |
| MG-EDN-10.5 |
| MG-EDN-11 |
| MG-EDN-11.5 |
| MG-EDN-12 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Blade diameter (D) (φ) | Blade length (ℓ) (mm) | Shank diameter (d) (mm) | Overall Length (L) (mm) | Tool No. | |
|---|---|---|---|---|---|---|---|---|---|
50.87 € | 1 | 6 Days | 3 | 10 | 6 | 50 | 8510030 | ||
53.61 € | 1 | 6 Days | 3.5 | 12 | 6 | 50 | 8510035 | ||
53.61 € | 1 | 6 Days | 4 | 14 | 6 | 50 | 8510040 | ||
62.37 € | 1 | 6 Days | 4.5 | 14 | 6 | 50 | 8510045 | ||
62.37 € | 1 | 6 Days | 5 | 17 | 6 | 60 | 8510050 | ||
67.83 € | 1 | 6 Days | 5.5 | 17 | 6 | 60 | 8510055 | ||
67.83 € | 1 | 6 Days | 6 | 17 | 6 | 60 | 8510060 | ||
81.01 € | 1 | 6 Days | 6.5 | 20 | 8 | 70 | 8510065 | ||
81.01 € | 1 | 6 Days | 7 | 20 | 8 | 70 | 8510070 | ||
89.42 € | 1 | 6 Days | 7.5 | 20 | 8 | 70 | 8510075 | ||
89.42 € | 1 | 6 Days | 8 | 24 | 8 | 70 | 8510080 | ||
83.96 € | 1 | 6 Days | 8.5 | 24 | 10 | 80 | 8510085 | ||
83.96 € | 1 | 6 Days | 9 | 24 | 10 | 80 | 8510090 | ||
92.08 € | 1 | 6 Days | 9.5 | 24 | 10 | 80 | 8510095 | ||
92.08 € | 1 | 6 Days | 10 | 28 | 10 | 80 | 8510100 | ||
107.25 € | 1 | 6 Days | 10.5 | 28 | 12 | 90 | 8510105 | ||
107.25 € | 1 | 6 Days | 11 | 28 | 12 | 90 | 8510110 | ||
115.92 € | 1 | 6 Days | 11.5 | 28 | 12 | 90 | 8510115 | ||
115.92 € | 1 | 6 Days | 12 | 34 | 12 | 90 | 8510120 |
Loading...
Basic information
| work material | General steel / Heat-Treated Steel / Cast Iron / Aluminum / Copper | Number of flutes(sheet) | 2 | Type | Square |
|---|---|---|---|---|---|
| Coating | Non-Coated | Machining Application | Flat Surface / Side Surface / Groove / Thrust (Z-Feed) / Inclined Cutting | Blade tip shape | Sharp Corner |
| Torsion Angle (θ) | Standard Helix (30 to 40°) | Blade diameter tolerance(mm) | 0～-0.03 |
Configure
Basic Attributes
-
Blade diameter (D)(φ)
-
Blade length (ℓ)(mm)
-
Shank diameter (d)(mm)
-
Overall Length (L)(mm)
-
Tool No.
-
Type
- MG-EDN
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
