Groove-Free Tap Series UM New Roll UM-NRT
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| UM-NRT-S0.5X0.125 |
| UM-NRT-S0.6X0.15 |
| UM-NRT-S0.7X0.175 |
| UM-NRT-S0.8X0.2-3 |
| UM-NRT-S0.8X0.2-5 |
| UM-NRT-S0.8X0.15 |
| UM-NRT-S0.9X0.225 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal | Pitch, Number of Threading (mm) | Thread Length (mm) | Tool No. | |
|---|---|---|---|---|---|---|---|---|
43.06 € | 1 | Available | 6 Days | S0.5 | 0.125 | 2 | 8317965 | |
38.59 € | 1 | Available | 6 Days | S0.6 | 0.15 | 2.5 | 8317971 | |
34.94 € | 1 | Available | 6 Days | S0.7 | 0.175 | 2.5 | 8317977 | |
31.64 € | 1 | Available | 6 Days | S0.8 | .02 | 3 | 8317983 | |
31.64 € | 1 | Available | 6 Days | S0.8 | 0.2 | 5 | 8317989 | |
31.64 € | 1 | Available | 6 Days | S0.8 | 0.15 | 5 | 8317992 | |
31.64 € | 1 | Available | 6 Days | S0.9 | 0.225 | 3 | 8317995 |
Loading...
Basic information
| Screw Types | Miniature | Chamfer threads | 2P | Tool Material Type | Powder high-speed steel |
|---|---|---|---|---|---|
| Work material | Low-Carbon Steel (carbon alloy less than 0.25%) / Stainless Steel (JIS-SUS) / Aluminum Rolled Material (AL) / Aluminum Alloy Casting (AC, ADC) / Zinc Alloy Casting (ZDC) | Tap Type | Roll tap | Hole type | For blind hole |
| Coating Y/N | Available | Coating Type | CrN | L(mm) | 30 |
| Accuracy | RH2 | Shank diameter(mm) | 3 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
