CPR for Resin Processing, 2-Flute Long Neck Square
- Volume Discount
· Long Neck End Mill for Resin Processing
· Ideal for deep grooving thanks to the undercut processing of the neck part
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Blade diameter (D) (φ) | Blade length (ℓ) (mm) | Shank diameter (d) (mm) | Overall Length (L) (mm) | Underneck length (ℓ1) (mm) | Blade tip shape | Neck diameter φd1 (mm) | Shank Taper Angle Bta (°) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
68.40 € | 1 | 6 Days | 0.5 | 1 | 3 | 38 | 2 | Sharp Edge | 0.45 | 11° | ||
68.40 € | 1 | 11 Days | 0.5 | 1 | 3 | 38 | 4 | Sharp Edge | 0.45 | 11° | ||
68.40 € | 1 | 6 Days | 0.5 | 1 | 3 | 38 | 6 | Sharp Edge | 0.45 | 11° | ||
62.27 € | 1 | 11 Days | 0.6 | 1.2 | 3 | 38 | 4 | Sharp Edge | 0.55 | 11° | ||
62.27 € | 1 | 6 Days | 0.6 | 1.2 | 3 | 38 | 6 | Sharp Edge | 0.55 | 11° | ||
62.27 € | 1 | 6 Days | 0.7 | 1.4 | 3 | 38 | 4 | Sharp Edge | 0.65 | 11° | ||
62.27 € | 1 | 11 Days | 0.7 | 1.4 | 3 | 38 | 6 | Sharp Edge | 0.65 | 11° | ||
52.19 € | 1 | 6 Days | 0.8 | 1.6 | 4 | 45 | 6 | Sharp Edge | 0.75 | 11° | ||
52.19 € | 1 | 11 Days | 0.8 | 1.6 | 4 | 45 | 8 | Sharp Edge | 0.75 | 11° | ||
52.19 € | 1 | 11 Days | 0.9 | 1.8 | 4 | 45 | 6 | Sharp Edge | 0.85 | 11° | ||
52.19 € | 1 | 6 Days | 0.9 | 1.8 | 4 | 45 | 10 | Sharp Edge | 0.85 | 11° | ||
40.79 € | 1 | Available |
Same day
Stock | 1 | 2 | 4 | 45 | 6 | Sharp Edge | 0.9 | 11° | |
33.05 € | 1 | Available |
Same day
Stock | 1 | 2 | 4 | 45 | 8 | Sharp Edge | 0.9 | 11° | |
52.19 € | 1 | 6 Days | 1 | 2 | 4 | 45 | 10 | Sharp Edge | 0.9 | 11° | ||
52.19 € | 1 | 6 Days | 1 | 2 | 4 | 45 | 12 | Sharp Edge | 0.9 | 11° | ||
52.19 € | 1 | 6 Days | 1 | 2 | 4 | 50 | 16 | Sharp Edge | 0.9 | 11° | ||
62.27 € | 1 | 6 Days | 1 | 2 | 4 | 55 | 21 | Sharp Edge | 0.9 | 11° | ||
52.19 € | 1 | 6 Days | 1.2 | 2.4 | 4 | 45 | 6 | Sharp Edge | 1.1 | 11° | ||
52.19 € | 1 | 6 Days | 1.2 | 2.4 | 4 | 45 | 8 | Sharp Edge | 1.1 | 11° | ||
52.19 € | 1 | 11 Days | 1.2 | 2.4 | 4 | 45 | 10 | Sharp Edge | 1.1 | 11° | ||
52.19 € | 1 | 11 Days | 1.2 | 2.4 | 4 | 50 | 12 | Sharp Edge | 1.1 | 11° | ||
52.19 € | 1 | 6 Days | 1.4 | 2.8 | 4 | 45 | 6 | Sharp Edge | 1.3 | 11° | ||
52.19 € | 1 | 6 Days | 1.4 | 2.8 | 4 | 45 | 10 | Sharp Edge | 1.3 | 11° | ||
52.19 € | 1 | 6 Days | 1.4 | 2.8 | 4 | 50 | 16 | Sharp Edge | 1.3 | 11° | ||
52.19 € | 1 | 6 Days | 1.5 | 3 | 4 | 45 | 6 | Sharp Edge | 1.4 | 11° | ||
52.19 € | 1 | 6 Days | 1.5 | 3 | 4 | 45 | 10 | Sharp Edge | 1.4 | 11° | ||
52.19 € | 1 | 6 Days | 1.5 | 3 | 4 | 50 | 14 | Sharp Edge | 1.4 | 11° | ||
52.19 € | 1 | 6 Days | 1.5 | 3 | 4 | 50 | 16 | Sharp Edge | 1.4 | 11° | ||
52.19 € | 1 | Available | 6 Days | 1.5 | 3 | 4 | 55 | 21 | Sharp Edge | 1.4 | 11° | |
52.19 € | 1 | 6 Days | 1.6 | 3.2 | 4 | 50 | 6 | Sharp Edge | 1.5 | 11° | ||
52.19 € | 1 | 6 Days | 2 | 4 | 4 | 50 | 8 | Sharp Edge | 1.9 | 11° | ||
52.19 € | 1 | 6 Days | 2 | 4 | 4 | 50 | 10 | Sharp Edge | 1.9 | 11° | ||
52.19 € | 1 | 6 Days | 2 | 4 | 4 | 50 | 12 | Sharp Edge | 1.9 | 11° | ||
52.19 € | 1 | 11 Days | 2 | 4 | 4 | 50 | 14 | Sharp Edge | 1.9 | 11° | ||
52.19 € | 1 | 6 Days | 2 | 4 | 4 | 50 | 16 | Sharp Edge | 1.9 | 11° | ||
52.19 € | 1 | 11 Days | 2 | 4 | 4 | 55 | 18 | Sharp Edge | 1.9 | 11° | ||
52.19 € | 1 | 12 Days | 2 | 4 | 4 | 55 | 21 | Sharp Edge | 1.9 | 11° | ||
52.19 € | 1 | 6 Days | 2 | 4 | 4 | 55 | 26 | Sharp Edge | 1.9 | 11° | ||
62.27 € | 1 | 6 Days | 2 | 4 | 4 | 70 | 32 | Sharp Edge | 1.9 | 11° | ||
57.46 € | 1 | 11 Days | 2.5 | 5 | 4 | 55 | 12 | Sharp Edge | 2.3 | 11° | ||
57.46 € | 1 | 11 Days | 2.5 | 5 | 4 | 55 | 21 | Sharp Edge | 2.3 | 11° | ||
63.59 € | 1 | 6 Days | 3 | 6 | 6 | 70 | 8 | With Lead | 2.8 | 11° | ||
63.59 € | 1 | 6 Days | 3 | 6 | 6 | 70 | 12 | With Lead | 2.8 | 11° | ||
63.59 € | 1 | 10 Days | 3 | 6 | 6 | 70 | 16 | With Lead | 2.8 | 11° | ||
63.59 € | 1 | 6 Days | 3 | 6 | 6 | 70 | 21 | With Lead | 2.8 | 11° | ||
63.59 € | 1 | 6 Days | 3 | 6 | 6 | 70 | 26 | With Lead | 2.8 | 11° | ||
77.62 € | 1 | 6 Days | 3 | 6 | 6 | 80 | 32 | With Lead | 2.8 | 11° | ||
83.78 € | 1 | 6 Days | 3 | 6 | 6 | 90 | 42 | With Lead | 2.8 | 11° | ||
67.54 € | 1 | 6 Days | 4 | 8 | 6 | 70 | 12 | With Lead | 3.8 | 11° | ||
67.54 € | 1 | 6 Days | 4 | 8 | 6 | 70 | 16 | With Lead | 3.8 | 11° | ||
67.54 € | 1 | 6 Days | 4 | 8 | 6 | 70 | 18 | With Lead | 3.8 | 11° | ||
67.54 € | 1 | 6 Days | 4 | 8 | 6 | 70 | 21 | With Lead | 3.8 | 11° | ||
67.54 € | 1 | 6 Days | 4 | 8 | 6 | 70 | 24 | With Lead | 3.8 | 11° | ||
67.54 € | 1 | 11 Days | 4 | 8 | 6 | 70 | 32 | With Lead | 3.8 | 11° | ||
67.54 € | 1 | 6 Days | 4 | 8 | 6 | 70 | 36 | With Lead | 3.8 | 11° | ||
70.62 € | 1 | 6 Days | 4 | 8 | 6 | 80 | 42 | With Lead | 3.8 | 11° | ||
91.22 € | 1 | 6 Days | 4 | 8 | 6 | 100 | 52 | With Lead | 3.8 | 11° | ||
77.62 € | 1 | 6 Days | 5 | 10 | 6 | 80 | 16 | With Lead | 4.8 | 11° | ||
77.62 € | 1 | 11 Days | 5 | 10 | 6 | 80 | 22 | With Lead | 4.8 | 11° | ||
77.62 € | 1 | 12 Days | 5 | 10 | 6 | 80 | 32 | With Lead | 4.8 | 11° |
Loading...
Basic information
| work material | Aluminum / Copper / Resin | Number of flutes(sheet) | 2 | Type | Long-Neck Square |
|---|---|---|---|---|---|
| Coating | Non-Coated | Machining Application | Plane / Side / Groove / Inclined Cuts | Torsion Angle (θ) | Standard Helix (30˚ to 40˚) |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Blade diameter (D)(φ)
-
Blade length (ℓ)(mm)
-
Shank diameter (d)(mm)
-
Overall Length (L)(mm)
-
Underneck length (ℓ1)(mm)
-
Blade tip shape
- Sharp Edge
- With Lead
-
Type
- CPR
Filter by standard shipping days
-
- All
- Same day
- 6 Days or Less
- 10 Days or Less
- 11 Days or Less
- 12 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
