MHR430R MUGEN-COATING 4-Flute Long Neck Radius End Mill

Promotional pricing ends 30/11/2024
Volume Discount

NS TOOL

Design dedicated for short blade length. Suppresses chatter by further reducing workpiece contact

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Products homepage

Data to be displayed: 30; 45; 60

Part Number
MHR430R-1-R0.05-3
MHR430R-1-R0.05-4
MHR430R-1-R0.05-5
MHR430R-1-R0.05-6
MHR430R-1-R0.05-8
MHR430R-1-R0.05-10
MHR430R-1-R0.05-12
MHR430R-1-R0.1-3
MHR430R-1-R0.1-4
MHR430R-1-R0.1-5
MHR430R-1-R0.1-6
MHR430R-1-R0.1-8
MHR430R-1-R0.1-10
MHR430R-1-R0.1-12
MHR430R-1-R0.2-3
MHR430R-1-R0.2-4
MHR430R-1-R0.2-5
MHR430R-1-R0.2-6
MHR430R-1-R0.2-8
MHR430R-1-R0.2-10
MHR430R-1-R0.2-12
MHR430R-1-R0.3-3
MHR430R-1-R0.3-4
MHR430R-1-R0.3-5
MHR430R-1-R0.3-6
MHR430R-1-R0.3-8
MHR430R-1-R0.3-10
MHR430R-1-R0.3-12
MHR430R-1.2-R0.1-5
MHR430R-1.2-R0.1-10
MHR430R-1.2-R0.1-15
MHR430R-1.2-R0.2-5
MHR430R-1.2-R0.2-10
MHR430R-1.2-R0.2-15
MHR430R-1.2-R0.3-5
MHR430R-1.2-R0.3-10
MHR430R-1.2-R0.3-15
MHR430R-1.5-R0.1-6
MHR430R-1.5-R0.1-12
MHR430R-1.5-R0.1-18
MHR430R-1.5-R0.2-6
MHR430R-1.5-R0.2-12
MHR430R-1.5-R0.2-18
MHR430R-1.5-R0.3-6
MHR430R-1.5-R0.3-12
MHR430R-1.5-R0.3-18
MHR430R-1.5-R0.5-6
MHR430R-1.5-R0.5-12
MHR430R-1.5-R0.5-18
MHR430R-2-R0.1-8
MHR430R-2-R0.1-12
MHR430R-2-R0.1-16
MHR430R-2-R0.1-20
MHR430R-2-R0.1-24
MHR430R-2-R0.2-8
MHR430R-2-R0.2-12
MHR430R-2-R0.2-16
MHR430R-2-R0.2-20
MHR430R-2-R0.2-24
MHR430R-2-R0.3-8

Standard Unit Price	Minimum order quantity	Volume Discount	Standard Shipping Days ?	Blade diameter (D) (φ)	R Size (mm)	Blade length (ℓ) (mm)	Overall Length (L) (mm)	Shank diameter (d) (mm)	Underneck length (ℓ1) (mm)	R Precision (μm)	Actual Effective Length for Workpiece Gradient Angle of 30' (mm)	Actual effective length at work slope angle 1° (mm)	Actual Effective Length for Workpiece Gradient Angle of 1°30' (mm)	Actual Effective Length for Workpiece Gradient Angle of 2° (mm)	Actual Effective Length for Workpiece Gradient Angle of 3° (mm)	Manufacturer Code	(d2) Neck Diameter (mm)	(γ) Neck Angle (°)
81.45 €	1	Available	8 Days	1	0.05	0.8	50	4	3	0.005～-0.005	3.26	3.4	3.56	3.73	4.13	08-00230-10021	0.95	12°
81.45 €	1	Available	6 Days	1	0.05	0.8	50	4	4	0.005～-0.005	4.3	4.49	4.7	4.93	5.46	08-00230-10022	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	5	0.005～-0.005	5.34	5.58	5.84	6.12	6.79	08-00230-10023	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	6	0.005～-0.005	6.38	6.67	6.98	7.32	8.11	08-00230-10024	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	8	0.005～-0.005	8.47	8.85	9.26	9.71	10.77	08-00230-10025	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	10	0.005～-0.005	10.56	11.03	11.54	12.11	13.42	08-00230-10026	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	12	0.005～-0.005	12.64	13.21	13.82	14.5	16.08	08-00230-10027	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	3	0.005～-0.005	3.25	3.4	3.55	3.72	4.12	08-00230-10031	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	4	0.005～-0.005	4.3	4.48	4.69	4.92	5.44	08-00230-10032	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	5	0.005～-0.005	5.34	5.57	5.83	6.11	6.77	08-00230-10033	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	6	0.005～-0.005	6.38	6.66	6.97	7.31	8.1	08-00230-10034	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	8	0.005～-0.005	8.47	8.84	9.25	9.7	10.75	08-00230-10035	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	10	0.005～-0.005	10.55	11.02	11.53	12.1	13.41	08-00230-10036	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	12	0.005～-0.005	12.64	13.2	13.81	14.49	16.06	08-00230-10037	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	3	0.005～-0.005	3.25	3.39	3.54	3.7	4.08	08-00230-10041	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	4	0.005～-0.005	4.29	4.48	4.68	4.9	5.41	08-00230-10042	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	5	0.005～-0.005	5.34	5.57	5.82	6.09	6.74	08-00230-10043	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	6	0.005～-0.005	6.38	6.66	6.96	7.29	8.07	08-00230-10044	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	8	0.005～-0.005	8.46	8.83	9.24	9.68	10.72	08-00230-10045	0.95	12°
81.45 €	1	Available	6 Days	1	0.05	0.8	50	4	10	0.005～-0.005	10.55	11.01	11.52	12.08	13.38	08-00230-10046	0.95	12°
81.45 €	1	Available	8 Days	1	0.05	0.8	50	4	12	0.005～-0.005	12.64	13.19	13.8	14.47	16.03	08-00230-10047	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	3	0.005～-0.005	3.25	3.38	3.52	3.68	4.05	08-00230-10051	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	4	0.005～-0.005	4.29	4.47	4.66	4.88	5.38	08-00230-10052	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	5	0.005～-0.005	5.33	5.56	5.8	6.07	6.71	08-00230-10053	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	6	0.005～-0.005	6.37	6.65	6.94	7.27	8.03	08-00230-10054	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	8	0.005～-0.005	8.46	8.83	9.22	9.66	10.69	08-00230-10055	0.95	12°
72.61 €	1	Available	6 Days	1	0.05	0.8	50	4	10	0.005～-0.005	10.55	11	11.51	12.06	13.34	08-00230-10056	0.95	12°
81.45 €	1	Available	6 Days	1	0.05	0.8	50	4	12	0.005～-0.005	12.63	13.18	13.79	14.45	16	08-00230-10057	0.95	12°
76.44 €	1	Available	6 Days	1.2	0.1	1	50	4	5	0.005～-0.005	5.36	5.6	5.86	6.14	6.8	08-00230-12031	1.15	12°
76.44 €	1	Available	6 Days	1.2	0.1	1	50	4	10	0.005～-0.005	10.58	11.05	11.56	12.12	13.44	08-00230-12032	1.15	12°
114.58 €	1	Available	6 Days	1.2	0.1	1	60	4	15	0.005～-0.005	15.79	16.49	17.26	18.11	20.07	08-00230-12033	1.15	12°
76.44 €	1	Available	6 Days	1.2	0.2	1	50	4	5	0.005～-0.005	5.36	5.59	5.84	6.12	6.77	08-00230-12041	1.15	12°
76.44 €	1	Available	6 Days	1.2	0.2	1	50	4	10	0.005～-0.005	10.57	11.04	11.55	12.11	13.41	08-00230-12042	1.15	12°
123.42 €	1	Available	6 Days	1.2	0.2	1	60	4	15	0.005～-0.005	15.79	16.49	17.25	18.09	20.04	08-00230-12043	1.15	12°
76.44 €	1	Available	6 Days	1.2	0.3	1	50	4	5	0.005～-0.005	5.36	5.58	5.83	6.1	6.74	08-00230-12051	1.15	12°
76.44 €	1	Available	6 Days	1.2	0.3	1	50	4	10	0.005～-0.005	10.57	11.03	11.53	12.09	13.37	08-00230-12052	1.15	12°
114.58 €	1	Available	6 Days	1.2	0.3	1	60	4	15	0.005～-0.005	15.78	16.48	17.24	18.07	20.01	08-00230-12053	1.15	12°
76.44 €	1	Available	6 Days	1.5	0.1	1.2	50	4	6	0.005～-0.005	6.42	6.7	7.01	7.35	8.15	08-00230-15031	1.45	12°
85.26 €	1	Available	6 Days	1.5	0.1	1.2	50	4	12	0.005～-0.005	12.68	13.24	13.85	14.53	16.11	08-00230-15032	1.45	12°
76.44 €	1	Available	6 Days	1.5	0.1	1.2	60	4	18	0.005～-0.005	18.93	19.78	20.7	21.71	24.07	08-00230-15033	1.45	12°
85.26 €	1	Available	6 Days	1.5	0.2	1.2	50	4	6	0.005～-0.005	6.42	6.69	7	7.33	8.11	08-00230-15041	1.45	12°
76.44 €	1	Available	6 Days	1.5	0.2	1.2	50	4	12	0.005～-0.005	12.67	13.23	13.84	14.51	16.08	08-00230-15042	1.45	12°
85.26 €	1	Available	6 Days	1.5	0.2	1.2	60	4	18	0.005～-0.005	18.93	19.77	20.68	21.69	24.04	08-00230-15043	1.45	12°
85.26 €	1	Available	6 Days	1.5	0.3	1.2	50	4	6	0.005～-0.005	6.41	6.68	6.98	7.31	8.08	08-00230-15051	1.45	12°
76.44 €	1	Available	6 Days	1.5	0.3	1.2	50	4	12	0.005～-0.005	12.67	13.22	13.83	14.49	16.04	08-00230-15052	1.45	12°
76.44 €	1	Available	6 Days	1.5	0.3	1.2	60	4	18	0.005～-0.005	18.92	19.76	20.67	21.67	24.01	08-00230-15053	1.45	12°
76.44 €	1	Available	6 Days	1.5	0.5	1.2	50	4	6	0.005～-0.005	6.4	6.67	6.96	7.27	8.02	08-00230-15061	1.45	12°
76.44 €	1	Available	6 Days	1.5	0.5	1.2	50	4	12	0.005～-0.005	12.66	13.2	13.8	14.45	15.98	08-00230-15062	1.45	12°
85.26 €	1	Available	6 Days	1.5	0.5	1.2	60	4	18	0.005～-0.005	18.92	19.74	20.64	21.63	23.94	08-00230-15063	1.45	12°
85.26 €	1	Available	6 Days	2	0.1	1.6	50	4	8	0.005～-0.005	8.55	8.93	9.35	9.8	10.86	08-00230-20031	1.94	12°
76.44 €	1	Available	6 Days	2	0.1	1.6	50	4	12	0.005～-0.005	12.73	13.29	13.91	14.59	16.17	08-00230-20032	1.94	12°
76.44 €	1	Available	6 Days	2	0.1	1.6	60	4	16	0.005～-0.005	16.9	17.65	18.47	19.37	Free	08-00230-20033	1.94	12°
76.44 €	1	Available	6 Days	2	0.1	1.6	60	4	20	0.005～-0.005	21.07	22.01	23.03	24.16	Free	08-00230-20034	1.94	12°
76.44 €	1	Available	6 Days	2	0.1	1.6	70	4	24	0.005～-0.005	25.24	26.36	27.59	28.95	Free	08-00230-20035	1.94	12°
76.44 €	1	Available	6 Days	2	0.2	1.6	50	4	8	0.005～-0.005	8.55	8.92	9.33	9.78	10.83	08-00230-20041	1.94	12°
76.44 €	1	Available	6 Days	2	0.2	1.6	50	4	12	0.005～-0.005	12.72	13.28	13.89	14.57	16.14	08-00230-20042	1.94	12°
76.44 €	1	Available	6 Days	2	0.2	1.6	60	4	16	0.005～-0.005	16.89	17.64	18.46	19.36	Free	08-00230-20043	1.94	12°
76.44 €	1	Available	6 Days	2	0.2	1.6	60	4	20	0.005～-0.005	21.06	22	23.02	24.14	Free	08-00230-20044	1.94	12°
76.44 €	1	Available	6 Days	2	0.2	1.6	70	4	24	0.005～-0.005	25.23	26.36	27.58	28.93	Free	08-00230-20045	1.94	12°
76.44 €	1	Available	6 Days	2	0.3	1.6	50	4	8	0.005～-0.005	8.55	8.91	9.32	9.76	10.8	08-00230-20051	1.94	12°

Basic information

work material	General steel / Quenched and tempered steel / High hardness steel –HRC55 / High hardness steel –HRC60 / High hardness steel –HRC65 / Stainless Steel / Aluminum / Titanium / Copper / Resin	Number of flutes(sheet)	4	Type	Long-Neck Radius
Machining Application	Plane / Side / Curved surface	Coating	TiAlN	Torsion Angle (θ)	Standard Helix (30˚ to 40˚)

Configure

146Suggestion of an applicable part number.

View Part Numbers
