Carbide End Mill CFRP Router Series Herringbone Type
Diamond-coated router with an superior abrasion resistance.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| DIA-HBC4-6 |
| DIA-HBC4-8 |
| DIA-HBC4-10 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Blade diameter (D) (φ) | Blade length (ℓ) (mm) | Shank diameter (d) (mm) | Overall Length (L) (mm) | Tool No. | |
|---|---|---|---|---|---|---|---|---|---|
98.04 € | 1 | 6 Days | 6 | 15 | 6 | 65 | 8809022 | ||
147.33 € | 1 | 6 Days | 8 | 20 | 8 | 70 | 8809023 | ||
205.29 € | 1 | 6 Days | 10 | 25 | 10 | 75 | 8809024 |
Loading...
Basic information
| Number of flutes(sheet) | 4 | Type | Roughing | Coating | Diamond Coat |
|---|---|---|---|---|---|
| Machining Application | Flat Surface / Side Surface / Inclined Cutting | Blade tip shape | With Lead | Torsion Angle (θ) | Standard Helix (30 to 40°) |
| Application | For composite material (CFRP) |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
