Soft Jaw (for Matsumoto)【3 Pieces Per Package】
- Correction sharpener is easy to use, and it also uses S45C steel which has a proper hardness. Furthermore, the occurrence of lowering and master key mounting distortions and restoration accuracy after re-mounting (run out) is subjected to careful consideration when deep processing.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| M-6 |
| M-8X |
| M-10 |
| M-12 |
| M-15 |
| Part Number |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Compatible Chuck Nominal Size | Jaw Height (mm) | Chuck Outer Diameter (mm) | Chuck diameter (Inch) | Pitch (mm) | Height (mm) | Length (mm) | Width (mm) | Trusco Code | Mass (g/group) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
71.62 € | 3 Pieces Per Package | 1 pack | 6 Days | 6 | 34 | 152.4 | 6 | 1.5 | 34 | 80 | 27.5 | 112-9139 | 1400 | ||
93.01 € | 3 Pieces Per Package | 1 pack | 10 Days | 8 | 40 | 203.2 | 8 | 1.5 | 40 | 90 | 36 | 112-9147 | 2400 | ||
144.34 € | 3 Pieces Per Package | 1 pack | 6 Days | 10 | 48 | 254 | 10 | 1.5 | 48 | 103 | 40 | 112-9155 | 3450 | ||
201.01 € | 3 Pieces Per Package | 1 pack | 6 Days | 12 | 50 | 304.8 | 12 | 1.5 | 50 | 140 | 50 | 112-9163 | 6400 | ||
270.13 € | 3 Pieces Per Package | 1 pack | 6 Days | 15～22 | 62 | 381～558.8 | 15 to 22 | 3 | 62 | 150 | 62 | 112-9171 | 10800 |
Loading...
Basic information
| Type | Soft Jaw | Mounting type | Serrated Type | Compatible Manufacturer | Matsumoto |
|---|---|---|---|---|---|
| Features | S45C steel, which can be easily cut for modification and features a suitable hardness, is used. Also, precise processing is performed with attention to lowering of the restoration accuracy (center runout) after reattachment and cause of attachment distortion of the master jaw. |
Configure
Basic Attributes
-
Compatible Chuck Nominal Size
-
Jaw Height(mm)
-
Chuck Outer Diameter(mm)
-
Chuck diameter(Inch)
-
Pitch(mm)
- 1.5
- 3
-
Height(mm)
-
Length(mm)
-
Width(mm)
-
Trusco Code
-
Type
- M
- M-X
Filter by standard shipping days
-
- All
- 6 Days or Less
- 10 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
