Taper Ball End Mill 2 Blades

Taper Ball End Mill 2 Blades

ATOM

ATOM

A small diameter taper ball end mill that standardizes maximum taper angles up to 15 degrees.

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Data to be displayed
30
45
60
  1. 1
  2. 2
  3. 3
  4. 4
  5. 5
  6. Next >>
Part Number
ATBES-20101
ATBES-20102
ATBES-20103
ATBES-20104
ATBES-20105
ATBES-20106
ATBES-20107
ATBES-20108
ATBES-20109
ATBES-20110
ATBES-20111
ATBES-20201
ATBES-20202
ATBES-20203
ATBES-20204
ATBES-20205
ATBES-20206
ATBES-20207
ATBES-20208
ATBES-20209
ATBES-20210
ATBES-20211
ATBES-20301
ATBES-20302
ATBES-20303
ATBES-20304
ATBES-20305
ATBES-20306
ATBES-20307
ATBES-20308
ATBES-20309
ATBES-20310
ATBES-20311
ATBES-20401
ATBES-20402
ATBES-20403
ATBES-20404
ATBES-20405
ATBES-20406
ATBES-20407
ATBES-20408
ATBES-20409
ATBES-20410
ATBES-20411
ATBES-20501
ATBES-20502
ATBES-20503
ATBES-20504
ATBES-20505
ATBES-20506
ATBES-20507
ATBES-20508
ATBES-20509
ATBES-20510
ATBES-20511
ATBES-20601
ATBES-20602
ATBES-20603
ATBES-20604
ATBES-20605
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Single corner (θ)
(Degree) 		Tip diameter D
(φ) 		Blade Length l
(mm) 		R
(mm) 		shank d
(mm) 		Overall Length L
(mm) 		Large End Diameter (φ) O.D. Tolerance
(mm) 		R Tolerance
(mm)

198.34 €

1 6 Days 30′0.10.50.053350.11+0/-0.015+0/-0.005

198.34 €

1 6 Days 1°0.10.50.053350.12+0/-0.015+0/-0.005

198.34 €

1 6 Days 1°30′0.10.50.053350.12+0/-0.015+0/-0.005

198.34 €

1 6 Days 2°0.10.50.053350.13+0/-0.015+0/-0.005

198.34 €

1 6 Days 2°30′0.10.50.053350.14+0/-0.015+0/-0.005

198.34 €

1 6 Days 3°0.10.50.053350.15+0/-0.015+0/-0.005

198.34 €

1 6 Days 4°0.10.50.053350.16+0/-0.015+0/-0.005

207.25 €

1 6 Days 5°0.10.50.053350.18+0/-0.015+0/-0.005

207.25 €

1 6 Days 7°0.10.50.053350.21+0/-0.015+0/-0.005

218.54 €

1 6 Days 10°0.10.50.053350.26+0/-0.015+0/-0.005

251.22 €

1 6 Days 15°0.10.50.053350.34+0/-0.015+0/-0.005

198.34 €

1 6 Days 30′0.210.13350.22+0/-0.015+0/-0.005

198.34 €

1 6 Days 1°0.210.13350.23+0/-0.015+0/-0.005

198.34 €

1 6 Days 1°30′0.210.13350.25+0/-0.015+0/-0.005

198.34 €

1 6 Days 2°0.210.13350.26+0/-0.015+0/-0.005

198.34 €

1 6 Days 2°30′0.210.13350.28+0/-0.015+0/-0.005

198.34 €

1 6 Days 3°0.210.13350.29+0/-0.015+0/-0.005

198.34 €

1 6 Days 4°0.210.13350.33+0/-0.015+0/-0.005

203.69 €

1 6 Days 5°0.210.13350.36+0/-0.015+0/-0.005

203.69 €

1 6 Days 7°0.210.13350.42+0/-0.015+0/-0.005

213.19 €

1 6 Days 10°0.210.13350.52+0/-0.015+0/-0.005

228.04 €

1 6 Days 15°0.210.13350.69+0/-0.015+0/-0.005

129.42 €

1 6 Days 30′0.31.50.153350.32+0/-0.015+0/-0.005

129.42 €

1 6 Days 1°0.31.50.153350.35+0/-0.015+0/-0.005

129.42 €

1 6 Days 1°30′0.31.50.153350.37+0/-0.015+0/-0.005

129.42 €

1 6 Days 2°0.31.50.153350.39+0/-0.015+0/-0.005

129.42 €

1 6 Days 2°30′0.31.50.153350.42+0/-0.015+0/-0.005

129.42 €

1 6 Days 3°0.31.50.153350.44+0/-0.015+0/-0.005

129.42 €

1 6 Days 4°0.31.50.153350.49+0/-0.015+0/-0.005

135.37 €

1 6 Days 5°0.31.50.153350.54+0/-0.015+0/-0.005

135.37 €

1 6 Days 7°0.31.50.153350.63+0/-0.015+0/-0.005

154.97 €

1 6 Days 10°0.31.50.153350.78+0/-0.015+0/-0.005

171.60 €

1 6 Days 15°0.31.50.153351.03+0/-0.015+0/-0.005

128.23 €

1 6 Days 30′0.420.23350.43+0/-0.015+0/-0.005

128.23 €

1 6 Days 1°0.420.23350.46+0/-0.015+0/-0.005

128.23 €

1 6 Days 1°30′0.420.23350.49+0/-0.015+0/-0.005

128.23 €

1 6 Days 2°0.420.23350.53+0/-0.015+0/-0.005

128.23 €

1 6 Days 2°30′0.420.23350.56+0/-0.015+0/-0.005

128.23 €

1 6 Days 3°0.420.23350.59+0/-0.015+0/-0.005

128.23 €

1 6 Days 4°0.420.23350.65+0/-0.015+0/-0.005

135.37 €

1 6 Days 5°0.420.23350.72+0/-0.015+0/-0.005

135.37 €

1 6 Days 7°0.420.23350.85+0/-0.015+0/-0.005

154.97 €

1 6 Days 10°0.420.23351.04+0/-0.015+0/-0.005

171.60 €

1 6 Days 15°0.420.23351.38+0/-0.015+0/-0.005

120.52 €

1 6 Days 30′0.520.253350.53+0/-0.015+0/-0.005

120.52 €

1 6 Days 1°0.520.253350.56+0/-0.015+0/-0.005

120.52 €

1 6 Days 1°30′0.520.253350.59+0/-0.015+0/-0.005

120.52 €

1 6 Days 2°0.520.253350.62+0/-0.015+0/-0.005

120.52 €

1 6 Days 2°30′0.520.253350.65+0/-0.015+0/-0.005

120.52 €

1 6 Days 3°0.520.253350.68+0/-0.015+0/-0.005

120.52 €

1 6 Days 4°0.520.253350.75+0/-0.015+0/-0.005

129.42 €

1 6 Days 5°0.520.253350.81+0/-0.015+0/-0.005

129.42 €

1 6 Days 7°0.520.253350.93+0/-0.015+0/-0.005

144.28 €

1 6 Days 10°0.520.253351.12+0/-0.015+0/-0.005

165.67 €

1 6 Days 15°0.520.253351.46+0/-0.015+0/-0.005

120.52 €

1 6 Days 30′0.630.33350.65+0/-0.015+0/-0.005

120.52 €

1 6 Days 1°0.630.33350.69+0/-0.015+0/-0.005

120.52 €

1 6 Days 1°30′0.630.33350.74+0/-0.015+0/-0.005

120.52 €

1 6 Days 2°0.630.33350.79+0/-0.015+0/-0.005

120.52 €

1 6 Days 2°30′0.630.33350.84+0/-0.015+0/-0.005

Loading...

  1. 1
  2. 2
  3. 3
  4. 4
  5. 5
  6. Next >>


Basic information

Type Taper ball work material General Steel / Quenched and tempered steel / Stainless Steel / Aluminum / Resin Number of flutes(sheet) 2
Torsion(°) 30

Configure

Clear all

330Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • Single corner (θ)(Degree)

    • 1°
    • 1°30′
    • 2°
    • 2°30′
    • 3°
    • 4°
    • 5°
    • 7°
    • 10°
    • 15°
    • 30′

    Clear

  • Tip diameter D(φ)

    • 0.1
    • 0.2
    • 0.3
    • 0.4
    • 0.5
    • 0.6
    • 0.7
    • 0.8
    • 0.9
    • 1
    • 1.1
    • 1.2
    • 1.3
    • 1.4
    • 1.5
    • 1.6
    • 1.7
    • 1.8
    • 1.9
    • 2
    • 2.1
    • 2.2
    • 2.3
    • 2.4
    • 2.5
    • 2.6
    • 2.7
    • 2.8
    • 2.9
    • 3

    Clear

  • Blade Length l(mm)

    • 0.5
    • 1
    • 1.5
    • 2
    • 3
    • 4
    • 8
    • 12

    Clear

  • R(mm)

    • 0.05
    • 0.1
    • 0.15
    • 0.2
    • 0.25
    • 0.3
    • 0.35
    • 0.4
    • 0.45
    • 0.5
    • 0.55
    • 0.6
    • 0.65
    • 0.7
    • 0.75
    • 0.8
    • 0.85
    • 0.9
    • 0.95
    • 1
    • 1.05
    • 1.1
    • 1.15
    • 1.2
    • 1.25
    • 1.3
    • 1.35
    • 1.4
    • 1.45
    • 1.5

    Clear

  • shank d(mm)

    • 3
    • 4
    • 6
    • 8
    • 10

    Clear

  • Overall Length L(mm)

    • 35
    • 50
    • 55

    Clear

  • Large End Diameter (φ)

    • 0.11
    • 0.12
    • 0.13
    • 0.14
    • 0.15
    • 0.16
    • 0.18
    • 0.21
    • 0.22
    • 0.23
    • 0.25
    • 0.26
    • 0.28
    • 0.29
    • 0.32
    • 0.33
    • 0.34
    • 0.35
    • 0.36
    • 0.37
    • 0.39
    • 0.42
    • 0.43
    • 0.44
    • 0.46
    • 0.49
    • 0.52
    • 0.53
    • 0.54
    • 0.56
    • 0.59
    • 0.62
    • 0.63
    • 0.65
    • 0.68
    • 0.69
    • 0.72
    • 0.74
    • 0.75
    • 0.78
    • 0.79
    • 0.81
    • 0.84
    • 0.85
    • 0.86
    • 0.88
    • 0.89
    • 0.93
    • 0.96
    • 0.98
    • 0.99
    • 1.02
    • 1.03
    • 1.04
    • 1.05
    • 1.07
    • 1.09
    • 1.12
    • 1.13
    • 1.15
    • 1.17
    • 1.18
    • 1.21
    • 1.23
    • 1.26
    • 1.27
    • 1.31
    • 1.33
    • 1.36
    • 1.38
    • 1.39
    • 1.4
    • 1.43
    • 1.46
    • 1.49
    • 1.52
    • 1.53
    • 1.56
    • 1.59
    • 1.62
    • 1.63
    • 1.65
    • 1.66
    • 1.69
    • 1.72
    • 1.73
    • 1.75
    • 1.78
    • 1.79
    • 1.81
    • 1.82
    • 1.85
    • 1.88
    • 1.91
    • 1.92
    • 1.94
    • 1.95
    • 1.98
    • 2.01
    • 2.02
    • 2.04
    • 2.05
    • 2.07
    • 2.08
    • 2.1
    • 2.13
    • 2.14
    • 2.15
    • 2.17
    • 2.19
    • 2.2
    • 2.23
    • 2.24
    • 2.26
    • 2.27
    • 2.29
    • 2.3
    • 2.32
    • 2.33
    • 2.36
    • 2.38
    • 2.39
    • 2.41
    • 2.42
    • 2.45
    • 2.48
    • 2.49
    • 2.5
    • 2.52
    • 2.55
    • 2.58
    • 2.59
    • 2.61
    • 2.64
    • 2.67
    • 2.68
    • 2.69
    • 2.7
    • 2.76
    • 2.77
    • 2.78
    • 2.79
    • 2.8
    • 2.83
    • 2.85
    • 2.87
    • 2.88
    • 2.89
    • 2.94
    • 2.96
    • 2.97
    • 2.99
    • 3.03
    • 3.05
    • 3.06
    • 3.07
    • 3.08
    • 3.11
    • 3.14
    • 3.15
    • 3.16
    • 3.17
    • 3.18
    • 3.2
    • 3.25
    • 3.26
    • 3.27
    • 3.29
    • 3.35
    • 3.36
    • 3.37
    • 3.38
    • 3.44
    • 3.45
    • 3.47
    • 3.54
    • 3.55
    • 3.56
    • 3.63
    • 3.64
    • 3.65
    • 3.66
    • 3.73
    • 3.74
    • 3.82
    • 3.83
    • 3.91
    • 3.92
    • 3.93
    • 4
    • 4.01
    • 4.02
    • 4.08
    • 4.1
    • 4.12
    • 4.16
    • 4.2
    • 4.21
    • 4.25
    • 4.29
    • 4.3
    • 4.33
    • 4.38
    • 4.39
    • 4.42
    • 4.48
    • 4.57
    • 4.67
    • 4.72
    • 4.76
    • 4.8
    • 4.85
    • 4.89
    • 4.98
    • 5.05
    • 5.07
    • 5.13
    • 5.16
    • 5.21
    • 5.25
    • 5.28
    • 5.34
    • 5.36
    • 5.42
    • 5.44
    • 5.51
    • 5.59
    • 5.6
    • 5.67
    • 5.75
    • 5.91
    • 5.99
    • 6.08
    • 6.16
    • 6.25
    • 6.33
    • 6.41
    • 6.5
    • 6.58
    • 6.67
    • 6.75
    • 7.97
    • 8.04
    • 8.12
    • 8.2
    • 8.27
    • 8.35
    • 8.43
    • 8.5
    • 8.58
    • 8.66
    • 8.73
