Insert for Cutter RGEN○○○
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| RGEN2004M0EN-VP15TF |
| RGEN2004M0SN-F7030 |
| RGEN2004M0SN-HTI10 |
| RGEN2004M0SN-UP20M |
| RGEN2004M0SN-UTI20T |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Work material | Honing | Nominal Code | Material Number | Material type | |
|---|---|---|---|---|---|---|---|---|---|
38.44 € | 10 | 6 Days | Steel / Stainless Steel / Cast Iron / Heat-resistant alloy, titanium alloy / High Hardness Material | E | RGEN2004M0EN | VP15TF | Coating | ||
38.44 € | 10 | 8 Days | Steel / Stainless Steel | S | RGEN2004M0SN | F7030 | Coating | ||
29.57 € | 10 | 6 Days | Cast Iron / Non-ferrous metal | S | RGEN2004M0SN | HTI10 | Carbide | ||
38.44 € | 10 | 9 Days | Steel / Stainless Steel | S | RGEN2004M0SN | UP20M | Coating | ||
29.57 € | 10 | 8 Days | Steel / Stainless Steel / Cast Iron | S | RGEN2004M0SN | UTi20T | Carbide |
Loading...
Basic information
| Shape (initial letter of model number) | R (Circular) | Clearance angle | G (30°) | D1(mm) | 20 |
|---|---|---|---|---|---|
| S1(mm) | 4.76 | Accuracy | E | Compatible cutter | SG20 |
| Corner height tolerance m(mm) | ±0.025 | Inscribed Circle Tolerance φD1(mm) | ±0.025 | Thickness Tolerance S1(mm) | ±0.025 |
| With/without Hole | NA | Presence of Breaker | NA | Selfishly | For both the left and right |
Configure
Basic Attributes
-
Work material
- Steel
- Stainless Steel
- Cast Iron
- Non-ferrous metal
- Heat-resistant alloy, titanium alloy
- High Hardness Material
-
Honing
- E
- S
-
Nominal Code
-
Material Number
-
Material type
- Carbide
- Coating
-
Type
- RGEN□□□
Filter by standard shipping days
-
- All
- 6 Days or Less
- 8 Days or Less
- 9 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
