Mag Height Block
- Volume Discount
For protection of the upper surface of a magnetic chuck. For improving precision of the upper surface of a magnetic chuck. (Capable of self-cutting) Fixed using mounting bolt. Avoids interference of through-hole drills, workpieces, etc.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| MHB-R50C-32 |
| MHB-R70C-15 |
| MHB-R70C-45 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | A (mm) | B (mm) | Mass (kg) | |
|---|---|---|---|---|---|---|---|
45.47 € | 1 | Available | 7 Days | 50 | 32 | 0.5 | |
42.17 € | 1 | Available | 7 Days | 70 | 15 | 0.4 | |
69.41 € | 1 | Available | 7 Days | 70 | 45 | 1.3 |
Loading...
Basic information
| Accessory | Mounting bolts | Features | For the protection of the upper surface of the magnet chuck. For improving precision of the upper surface of the magnet chuck. (Capable of self-cutting) Fixed using mounting bolt. Avoids interference of through-hole drills, workpieces, etc. | Material | SS Material |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
