G Cobalt Straight Shank Drill GCOSD

G Cobalt Straight Shank Drill GCOSD
  • Volume Discount

NACHI(FUJIKOSHI)

NACHI(FUJIKOSHI)

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
Part Number
GCOSD3.3
GCOSD7.0
GCOSD10.5
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Diameter Dc
(mm) 		Groove Length L
(mm) 		Overall Length L
(mm)

15.38 €

1 Available 6 Days 3.32973

31.23 €

1 Available 6 Days 747105

74.93 €

1 Available 6 Days 10.565137

Loading...

  1. 1

Basic information

work material General Steel / Quenched and tempered steel / Stainless Steel / Cast Iron / Aluminum / Copper Tool Material Type Cobalt HSS Shank Type Straight Shank
Coating Y/N Available Coating Type TiN With/without Oil Hole N/A
tip angle(Degree) 135 Torsional Angle(°) 28～36 Diameter tolerance(mm) h8

Configure

Clear all

3Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • Diameter Dc(mm)

    • 3.3
    • 7
    • 10.5

    Clear

  • Groove Length L(mm)

    • 29
    • 47
    • 65

    Clear

  • Overall Length L(mm)

    • 73
    • 105
    • 137

    Clear

  • Type

    • GCOSD

    Clear

Filter by standard shipping days

    • All
    • 6 Days or Less

    Reset

Optional Attributes
