Free Vise (2-pc Set)【2 Pieces Per Package】
- Volume Discount
[Features]
· Use this free vise if the workpiece is too large and cannot be installed on a vise, etc.
· The base surface of the main body is processed with key groove to use step keys.
· Use this free vise if the workpiece is too large and cannot be installed on a vise, etc.
· The base surface of the main body is processed with key groove to use step keys.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| FV350N |
| FV450N |
| FV550N |
| Part Number |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Width (mm) | Stroke (mm) | Mass (kg) | Accessory | Tightening Force (kN) | |
|---|---|---|---|---|---|---|---|---|---|---|
960.65 € | 2 Pieces Per Package | 1 pack | 5 Days | 70 | 5 | 6.8 | Two Cap Screws (CS610), 2 Step Keys (FKY16), 4 T Slot Bolts (TBM1275), 4 Flange Nuts (12MSFN) | 23 | ||
1,334.11 € | 2 Pieces Per Package | 1 pack | Available | 5 Days | 85 | 5 | 13 | Two Cap Screws (CS610), 2 Step Keys (FKY18), 4 T Slot Bolts (TBM1675), 4 Flange Nuts (16MSFN) | 28 | |
2,011.27 € | 2 Pieces Per Package | 1 pack | 5 Days | 110 | 7 | 21 | Two Cap Screws (CS610), 2 Step Keys (FKY20), 4 T Slot Bolts (TBM20100), 4 Flange Nuts (20MSFN) | 38 |
Loading...
Basic information
| Details Type | Free Vise | Material | FCD450 | Finishing | Black Oxide / Mouthpiece with Grinding Finish |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
