Stainless Steel Socket (Hex Type) - Square Drive 9.5 mm
- Volume Discount
[Features]
· Square drive: 9.5 mm.
· Stainless steel socket for tightening and loosening bolts and nuts.
· The material used is precipitation hardening stainless steel, with the focus on strength.
· Rust-resistant, corrosion-resistant, chemical-resistant stainless steel, which is excellent from the hygiene perspective.
[Applications]
· Food-processing equipment, Medical industry, Clean rooms, Precision machinery, Ships, Marine sports, Ocean development.
· Plants, Waterproofing, Waterworks, Cleaning equipment, etc.
· Ideal in places where stainless steel bolts and nuts are used.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| S3V-08 |
| S3V-12 |
| S3V-13 |
| S3V-14 |
| S3V-17 |
| S3V-19 |
| S3V-21 |
| S3V-22 |
| S3V-24 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Single Product/Set Classification | Socket shape | Overall length (L dimension) (mm) | Width across flat dimension (S Measurement) (inch) | Opposite side dimensions (mm) | Overall Length | JAN Code | Trusco Code | Width across flat part external diameter (measurement D1) (mm) | Maximum Outer Diameter (D1 or D2 Dimensions) (mm) | Width across flat part depth (measurement L1) (mm) | Through Hole I.D. (d Dimension) (mm) | Mass (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
41.52 € | 1 | Available | 9 Days | Single Item Socket | - | 23 | - | 8 | 23 | 4953488306200 | 474-3130 | - | - | - | - | 18 | |
46.02 € | 1 | Available | 9 Days | Single Item Handle | 6 Sq. | 24 | 11/16 | - | - | - | - | 24.2 | 23 | 12.5 | 14 | 22 | |
46.69 € | 1 | Available | 9 Days | Single Item Handle | 6 Sq. | 25.5 | 13/16 | - | - | - | - | 27.4 | 24 | 17.5 | 18 | 27 | |
48.16 € | 1 | Available | 9 Days | Single Item Socket | - | 26 | - | 14 | 26 | 4953488306248 | 474-3172 | - | - | - | - | 30 | |
55.74 € | 1 | Available | 9 Days | Single Item Socket | - | 28.5 | - | 17 | 28.5 | 4953488306255 | 474-0025 | - | - | - | - | 43 | |
57.22 € | 1 | Available | 9 Days | Single Item Socket | - | 30 | - | 19 | 30 | 4953488306262 | 474-3164 | - | - | - | - | 57 | |
58.65 € | 1 | Available | 9 Days | Single Item Handle | 6 Sq. | 32 | 1/4 | - | - | - | - | 10.4 | 16.8 | 4.7 | 5.5 | 67 | |
60.80 € | 1 | Available | 9 Days | Single Item Handle | 6 Sq. | 32 | 9/16 | - | - | - | - | 20.7 | 21.5 | 11.4 | 11 | 75 | |
69.95 € | 1 | Available | 9 Days | Single Item Socket | - | 35 | - | 24 | 35 | 4953488306293 | 474-3199 | - | - | - | - | 90 |
Loading...
Basic information
| Application | For handwork | Insertion Angle (Shaft measurement when electric drill) (mm) | 9.5 |
|---|
Configure
Basic Attributes
-
Single Product/Set Classification
- Single Item Socket
- Single Item Handle
-
Socket shape
-
Overall length (L dimension)(mm)
-
Width across flat dimension (S Measurement)(inch)
-
Opposite side dimensions(mm)
-
Overall Length
- 23
- 26
- 28.5
- 30
- 35
-
JAN Code
-
Trusco Code
-
Type
- S3SB
- S3V
- S4SB
Filter by standard shipping days
-
- All
- 9 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
