Electrocoated Diamond Bar Shaft Diameter 6 mm
[Features]
· Large diamond abrasive grain protrusions for excellent sharpness.
· Ideal for rough grinding when a finish surface roughness is not required.
[Applications]
· Applicable Materials: Ceramics, Glass, Tool Steel, Alloy Steel, Cemented Carbide, Cermet
· Large diamond abrasive grain protrusions for excellent sharpness.
· Ideal for rough grinding when a finish surface roughness is not required.
[Applications]
· Applicable Materials: Ceramics, Glass, Tool Steel, Alloy Steel, Cemented Carbide, Cermet
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
AD3102
Basic information
| Particle Size(#) | 100 | Shape | Cylinder Type | Diamond Maximum Diameter(mm) | 4 |
|---|---|---|---|---|---|
| Shaft Diameter(mm) | 6 | Max. Rotational Speed(rpm) | 80000 | Overall Length(mm) | 55.5 |
| Blade Length(mm) | 5 | Mass(g) | 13 | JAN Code | 4571130852136 |
| Trusco Code | 498-7403 |
This page is Electrocoated Diamond Bar Shaft Diameter 6 mm, part number AD3102.
You can find the detail information about specifications and dimensions on part number AD3102.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
