SUS Socket (Hexagonal) S4SB
- Volume Discount
· Stainless steel sockets in inch-size.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| S4SB-12 |
| S4SB-14 |
| S4SB-16 |
| S4SB-18 |
| S4SB-20 |
| S4SB-22 |
| S4SB-24 |
| S4SB-26 |
| S4SB-28 |
| S4SB-30 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Single Product/Set Classification | Application | Socket shape | Overall length (L dimension) (mm) | Width across flat dimension (S Measurement) (inch) | Opposite side dimensions (mm) | Overall Length | JAN Code | Trusco Code | Width across flat part external diameter (measurement D1) (mm) | Maximum Outer Diameter (D1 or D2 Dimensions) (mm) | Width across flat part depth (measurement L1) (mm) | Through Hole I.D. (d Dimension) (mm) | Mass (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
64.75 € | 1 | Available | 9 Days | Single Item Handle | For handwork | 6 Sq. | 31 | 3/8 | - | - | - | - | 15.5 | 21.5 | 8 | 8.8 | 42 | |
64.77 € | 1 | Available | 9 Days | - | - | - | - | - | 10 | 32.5 | 4953488309355 | 474-3148 | - | - | - | - | 44 | |
64.78 € | 1 | Available | 5 Days | Single Item Handle | For handwork | 6 Sq. | 33 | 1/2 | - | - | - | - | 18.8 | 21.5 | 9.8 | 10.5 | 45 | |
64.83 € | 1 | Available | 9 Days | - | - | - | - | - | 22 | 35 | 4953488309379 | 474-0041 | - | - | - | - | 50 | |
70.63 € | 1 | Available | 8 Days | Single Item Handle | For handwork | 6 Sq. | 35.5 | 5/8 | - | - | - | - | 22.4 | 23 | 11.5 | 14 | 59 | |
70.70 € | 1 | Available | 9 Days | - | - | - | - | - | 14 | 36.5 | 4953488309393 | 474-3172 | - | - | - | - | 67 | |
70.81 € | 1 | Available | 5 Days | Single Item Handle | For handwork | 6 Sq. | 37.5 | 3/4 | - | - | - | - | 26.5 | 24 | 18 | 18 | 78 | |
74.51 € | 1 | Available | 9 Days | Single Item Handle | For handwork | 6 Sq. | 38 | 7/16 | - | - | - | - | 27.4 | 24 | 17.5 | 18 | 78 | |
74.70 € | 1 | Available | 9 Days | Single Item Handle | For handwork | 6 Sq. | 41 | 7/8 | - | - | - | - | 29.5 | 26 | 21 | 18 | 98 | |
80.49 € | 1 | Available | 8 Days | Single Item Handle | For handwork | 6 Sq. | 41 | 3/8 | - | - | - | - | 31.5 | 26 | 20 | 20 | 108 |
Loading...
Basic information
| Insertion Angle (Shaft measurement when electric drill) (mm) | 12.7 | Material | Martensitic stainless steel |
|---|
Configure
Basic Attributes
-
Single Product/Set Classification
- Single Item Handle
-
Application
- For handwork
-
Socket shape
-
Overall length (L dimension)(mm)
-
Width across flat dimension (S Measurement)(inch)
-
Opposite side dimensions(mm)
-
Overall Length
- 32.5
- 35
- 36.5
-
JAN Code
-
Trusco Code
-
Type
- S3SB
- S3V
- S4SB
Filter by standard shipping days
-
- All
- 5 Days or Less
- 8 Days or Less
- 9 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
