1810BD Hook wrench with pin
- Volume Discount
Special steel, hardened and high-grade zinc-plated.
Rounded edges for better handling. The product is available per 1 peace.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 55400 |
| 55418 |
| 55426 |
| 55434 |
| 55442 |
| 55459 |
| 55467 |
| 55475 |
| 55483 |
| 55491 |
| 55509 |
| 55517 |
| 55525 |
| 55533 |
| 55541 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | L (mm) | dia. D | Size | T | |
|---|---|---|---|---|---|---|---|---|---|
10.10 € | 1 | Available | 5 Days | 10 | 110 | 2,5 | 16- 18 | 3 | |
11.17 € | 1 | Available | 5 Days | 10 | 110 | 2,5 | 20- 22 | 3 | |
11.21 € | 1 | Available | 5 Days | 10 | 136 | 3 | 25- 28 | 4 | |
11.21 € | 1 | Available | 5 Days | 10 | 136 | 4 | 30- 32 | 4 | |
12.31 € | 1 | Available | 5 Days | 10 | 170 | 4 | 34- 36 | 5 | |
12.87 € | 1 | Available | 5 Days | 10 | 170 | 4 | 40- 42 | 5 | |
15.60 € | 1 | Available | 5 Days | 10 | 206 | 5 | 45- 50 | 6 | |
15.54 € | 1 | Available | 5 Days | 10 | 206 | 5 | 52- 55 | 6 | |
21.08 € | 1 | Available | 5 Days | 10 | 240 | 5 | 58 -62 | 7 | |
21.08 € | 1 | Available | 5 Days | 10 | 240 | 6 | 68- 75 | 7 | |
26.27 € | 1 | Available | 5 Days | 10 | 280 | 6 | 80- 90 | 8 | |
25.94 € | 1 | Available | 5 Days | 10 | 280 | 8 | 95-100 | 8 | |
44.61 € | 1 | Available | 5 Days | 10 | 335 | 8 | 110-115 | 8* | |
49.81 € | 1 | Available | 5 Days | 10 | 335 | 8 | 120-130 | 8* | |
57.14 € | 1 | Available | 5 Days | 10 | 380 | 8 | 135-145 | 8* |
Loading...
Configure
Basic Attributes
-
L(mm)
-
dia. D
-
Size
-
T
-
Type
- 554
- 555
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
