GANTER

Flanged base plate connector clamps, Aluminium

Flanged base plate connector clamps, Aluminium

Part number:

Still undefined. 28 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    171-B20-2-BL
    171-B20-2-SW
    171-B25-2-BL
    171-B25-2-SW
    171-B30-2-BL
    171-B30-2-SW
    171-B40-2-BL
    171-B40-2-SW
    Order suspended
    171-B42-2-BL
    171-B42-2-SW
    171-B45-2-BL
    Order suspended
    171-B45-2-SW
    171-B48-2-BL
    171-B48-2-SW
    171-B50-2-BL
    171-B50-2-SW
    171-V20-2-BL
    171-V20-2-SW
    171-V25-2-BL
    171-V25-2-SW
    171-V30-2-BL
    171-V30-2-SW
    171-V40-2-BL
    171-V40-2-SW
    171-V45-2-BL
    Order suspended
    171-V45-2-SW
    171-V50-2-BL
    171-V50-2-SW

    Bore d1

    Square s

    Finish

    Weight

    (kg)

    		Minimum order quantity
    B 20
    -
    BL-blank
    0.344
    1 pieces
    B 20
    -
    SW - black, RAL 9005, textured finish
    0.344
    1 pieces
    B 25
    -
    BL-blank
    0.337
    1 pieces
    B 25
    -
    SW - black, RAL 9005, textured finish
    0.337
    1 pieces
    B 30
    -
    BL-blank
    0.330
    1 pieces
    B 30
    -
    SW - black, RAL 9005, textured finish
    0.330
    1 pieces
    B 40
    -
    BL-blank
    0.968
    1 pieces
    B 40
    -
    SW - black, RAL 9005, textured finish
    0.968
    1 pieces
    B 42
    -
    BL-blank
    0.995
    1 pieces
    B 42
    -
    SW - black, RAL 9005, textured finish
    0.995
    1 pieces
    B 45
    -
    BL-blank
    0.982
    1 pieces
    B 45
    -
    SW - black, RAL 9005, textured finish
    0.982
    1 pieces
    B 48
    -
    BL-blank
    0.973
    1 pieces
    B 48
    -
    SW - black, RAL 9005, textured finish
    0.973
    1 pieces
    B 50
    -
    BL-blank
    0.959
    1 pieces
    B 50
    -
    SW - black, RAL 9005, textured finish
    0.959
    1 pieces
    -
    V 20
    BL-blank
    0.343
    1 pieces
    -
    V 20
    SW - black, RAL 9005, textured finish
    0.343
    1 pieces
    -
    V 25
    BL-blank
    0.326
    1 pieces
    -
    V 25
    SW - black, RAL 9005, textured finish
    0.326
    1 pieces
    -
    V 30
    BL-blank
    0.316
    1 pieces
    -
    V 30
    SW - black, RAL 9005, textured finish
    0.316
    1 pieces
    -
    V 40
    BL-blank
    0.981
    1 pieces
    -
    V 40
    SW - black, RAL 9005, textured finish
    0.981
    1 pieces
    -
    V 45
    BL-blank
    0.958
    1 pieces
    -
    V 45
    SW - black, RAL 9005, textured finish
    0.958
    1 pieces
    -
    V 50
    BL-blank
    0.918
    1 pieces
    -
    V 50
    SW - black, RAL 9005, textured finish
    0.918
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    46.52 €
    ( 55.36 € )
    7 working days
    46.58 €
    ( 55.43 € )
    7 working days
    46.52 €
    ( 55.36 € )
    7 working days
    46.58 €
    ( 55.43 € )
    7 working days
    46.52 €
    ( 55.36 € )
    7 working days
    46.58 €
    ( 55.43 € )
    7 working days
    59.84 €
    ( 71.21 € )
    7 working days
    59.88 €
    ( 71.26 € )
    7 working days
    59.32 €
    ( 70.59 € )
    7 working days
    58.84 €
    ( 70.02 € )
    7 working days
    58.78 €
    ( 69.95 € )
    7 working days
    58.82 €
    ( 70.00 € )
    7 working days
    59.32 €
    ( 70.59 € )
    7 working days
    59.36 €
    ( 70.64 € )
    7 working days
    59.32 €
    ( 70.59 € )
    7 working days
    59.36 €
    ( 70.64 € )
    7 working days
    46.52 €
    ( 55.36 € )
    7 working days
    46.58 €
    ( 55.43 € )
    7 working days
    46.52 €
    ( 55.36 € )
    7 working days
    46.58 €
    ( 55.43 € )
    7 working days
    46.30 €
    ( 55.10 € )
    7 working days
    46.34 €
    ( 55.14 € )
    7 working days
    59.32 €
    ( 70.59 € )
    7 working days
    59.36 €
    ( 70.64 € )
    7 working days
    59.32 €
    ( 70.59 € )
    7 working days
    58.56 €
    ( 69.69 € )
    7 working days
    59.32 €
    ( 70.59 € )
    7 working days
    59.36 €
    ( 70.64 € )
    7 working days
  • 1

    • More Information

    Basic information

    The clamping bores of GN 171 flanged base plate connector clamps are not machined and specially designed for construction tubes GN 990 or DIN 2391, DIN 2395 and DIN 2462 respectively.
    The square versions are also suitable for profile systems.

    The standard clamping screws are socket cap screws DIN 912. They can be replaced by clamping kits GN 911 (article code see table of dimensions).
