Blade for double action air scissor
· Blade opening and closing is driven by air piston.
· Having no spring mechanism in the main unit facilitates maintenance.
· Having no spring mechanism in the main unit facilitates maintenance.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
No. HW1J/HW10J Blade for Double Action Air Scissors
Product Information
● Blade opening and closing is driven by air piston.
● Having no spring mechanism in the main unit facilitates maintenance.
Specifications
Applicable Blade Specifications
| Model No. | Blade Opening (mm) | Cutting brade effective (mm） | A (mm) | Weight (g) | EDP No. |
| For GT-HWR1/HWS1 | |||||
| HW1J | 3.0 | 17 | 25 | 16 | 360452 |
| For GT-HWS10 | |||||
| HW10J | 5.0 | 28 | 40 | 76 | 360462 |
Loading...
Basic information
| Materials | Special alloy steel |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
