Tool Shaft with Ball, Square, Internal Hexagon 1/4" C6.3
Click on this image to zoom in.
Click on this image to zoom in.
Drive: DIN 3120, ISO 1174, style A 6.3 + A 10.
Drive: DIN 3126, ISO 1173, style C 6.3.
Application: For hand used nut driver sockets.
Bits: Reduced, over-tightened profile.
Standards: DIN 3121, ISO 1174, Style A6,3
For universal applications
DIN 3126, ISO 1173, Style C6,3
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
01933
Basic information
| Overall length (L dimension)(mm) | 25 | Overall length(mm) | 25 | Blister pack | No |
|---|---|---|---|---|---|
| VDE article | No | ESD article | No | with battery | No |
| Square 1(Inch) | 1/4" | Internal hexagon(Inch) | 1/4" |
This page is Tool Shaft with Ball, Square, Internal Hexagon 1/4" C6.3, part number 01933.
You can find the detail information about specifications and dimensions on part number 01933.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
