L-Key with Key Handle, TORX®, Black Oxidized
Application: For high torque transfer with small screws, especially when replacing indexable inserts on milling heads.
Handle: Wiha key handle.
Blade: Chrome-vanadium steel, through-hardened, bronzed.
For applications in mechanics
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 01350 |
| 01351 |
| 01352 |
| 01353 |
| 01354 |
| 01355 |
| 01356 |
| 04918 |
| 26181 |
| 26182 |
| 26183 |
| 26184 |
| 26185 |
| 26186 |
| 26187 |
| 26188 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Overall length (L dimension) (mm) | Overall length (mm) | Round blade diameter (mm) | TORX® 1 | TORX PLUS® | Length T-handle blade | |
|---|---|---|---|---|---|---|---|---|---|---|---|
3.58 € | 10 | 7 Days | 70 | 70 | 2 | T6 | - | 35 | |||
3.58 € | 10 | 7 Days | 70 | 70 | 2.5 | T7 | - | 35 | |||
3.58 € | 10 | 7 Days | 75 | 75 | 2.5 | T8 | - | 40 | |||
3.94 € | 10 | 7 Days | 75 | 75 | 3 | T9 | - | 40 | |||
4.04 € | 10 | 7 Days | 75 | 75 | 3 | T10 | - | 40 | |||
4.19 € | 10 | 7 Days | 80 | 80 | 3.5 | T15 | - | 45 | |||
4.59 € | 10 | 7 Days | 80 | 80 | 4 | T20 | - | 45 | |||
3.58 € | 10 | 7 Days | 70 | 70 | 2 | T5 | - | 35 | |||
6.11 € | 10 | 3 Days | 70 | 70 | 2 | - | 5IP | 35 | |||
6.11 € | 10 | 3 Days | 70 | 70 | 2 | - | 6IP | 35 | |||
6.11 € | 10 | 3 Days | 70 | 70 | 2.5 | - | 7IP | 35 | |||
6.11 € | 10 | 3 Days | 75 | 75 | 2.5 | - | 8IP | 40 | |||
6.60 € | 10 | 3 Days | 75 | 75 | 3 | - | 9IP | 40 | |||
6.71 € | 10 | 3 Days | 75 | 75 | 3 | - | 10IP | 40 | |||
7.02 € | 10 | 3 Days | 80 | 80 | 3.5 | - | 15IP | 45 | |||
7.87 € | 10 | 3 Days | 80 | 80 | 4 | - | 20IP | 45 |
Loading...
Basic information
| Handle width (T-handle)(mm) | 40 | Blister pack | No | VDE article | No |
|---|---|---|---|---|---|
| ESD article | No | with battery | No |
Configure
Basic Attributes
-
Overall length (L dimension)(mm)
-
Overall length(mm)
-
Round blade diameter(mm)
-
TORX® 1
-
TORX PLUS®
-
Length T-handle blade
- 35
- 40
- 45
-
Type
Filter by standard shipping days
-
- All
- 3 Days or Less
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
