ABSOLUTE Digimatic Scale Unit

Catalog

Part number:

Still undefined. 83 possible part numbers found.

Part number list
More Information
Catalog

Part number list

Number of items

Part number

Accuracy

(inch)

Accuracy

(mm)

Additional Spec

DATA (output with Cable) / Hold (display value)

Diameter Function

Dust/Water Protection Level

Functions

Inch-Metric

Low Voltage Alarm

Mass

(kg)

Max. Response Speed

Max. Drive Speed

ON/OFF

ORIGIN

ORIGIN (ABS-Zero)

Range

(inch)

Repeatability

(mm)

Minimum order quantity

Data sheet	-	0.03	100 mm	-	-	-	Horizontal	Metric	Yes	0.23	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	150 mm	-	-	-	Horizontal	Metric	Yes	0.25	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	200 mm	-	-	-	Horizontal	Metric	Yes	0.27	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.04	300 mm	-	-	-	Horizontal	Metric	Yes	0.37	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	8 inch, 200 mm	-	-	-	Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.002	0.04	12 inch, 300 mm	-	-	-	Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	100 mm	-	-	-	Vertical	Metric	Yes	0.25	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	150 mm	-	-	-	Vertical	Metric	Yes	0.28	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	200 mm	-	-	-	Vertical	Metric	Yes	0.31	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.04	300 mm	-	-	-	Vertical	Metric	Yes	0.37	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	4 inch, 100 mm	-	-	-	Vertical	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	6 inch, 150 mm	-	-	-	Vertical	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	8 inch, 200 mm	-	-	-	Vertical	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.002	0.04	12 inch, 300 mm	-	-	-	Vertical	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	100 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal, Preset	Metric	Yes	0.25	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	150 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal, Preset	Metric	Yes	0.28	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	200 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal, Preset	Metric	Yes	0.31	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.04	300 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal, Preset	Metric	Yes	0.37	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.04	450 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal, Preset	Metric	Yes	0.76	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.05	600 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal, Preset	Metric	Yes	0.9	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.07	1000 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal, Preset	Metric	Yes	2.04	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	4 inch, 100 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	6 inch, 150 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	8 inch, 200 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.002	0.04	12 inch, 300 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.002	0.04	18 inch, 450 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.002	0.04	24 inch, 600 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.0025	0.06	32 inch, 800 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.0025	0.07	40 inch, 1000 mm	-	-	-	Without diameter function, With reversible counting direction, Horizontal	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	100 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Metric	Yes	0.25	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	150 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Metric	Yes	0.28	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	200 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Metric	Yes	0.31	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.04	300 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Metric	Yes	0.37	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.04	450 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Metric	Yes	0.76	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.05	600 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Metric	Yes	0.9	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.06	800 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Metric	Yes	1.71	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.07	1000 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Metric	Yes	2.04	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	4 inch, 100 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	6 inch, 150 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.001	0.03	8 inch, 200 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.002	0.04	12 inch, 300 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.002	0.04	18 inch, 450 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.002	0.04	24 inch, 600 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.0025	0.06	32 inch, 800 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	0.0025	0.07	40 inch, 1000 mm	Yes	Yes	-	Horizontal multi-function type with diameter displaying function	Inch/Metric	Yes	-	Unlimited	-	Yes	Yes	-	-	-	1 pieces
Data sheet	-	0.03	100 mm	Yes	-	-	Vertical	Metric	-	0.25	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	-	0.03	150 mm	Yes	-	-	Vertical	Metric	-	0.28	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	-	0.03	200 mm	Yes	-	-	Vertical	Metric	-	0.31	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	-	0.04	300 mm	Yes	-	-	Vertical	Metric	-	0.37	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	-	0.04	450 mm	Yes	-	-	Vertical	Metric	-	0.76	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	-	0.05	600 mm	Yes	-	-	Vertical	Metric	-	0.9	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	-	0.06	800 mm	Yes	-	-	Vertical	Metric	-	1.71	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	-	0.07	1000 mm	Yes	-	-	Vertical	Metric	-	2.04	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	0.001	0.03	4 inch, 100 mm	Yes	-	-	Vertical	Inch/Metric	-	-	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	0.001	0.03	6 inch, 150 mm	Yes	-	-	Vertical	Inch/Metric	-	-	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	0.001	0.03	8 inch, 200 mm	Yes	-	-	Vertical	Inch/Metric	-	-	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	0.001	0.03	12 inch, 300 mm	Yes	-	-	Vertical	Inch/Metric	-	-	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	0.002	0.04	18 inch, 450 mm	Yes	-	-	Vertical	Inch/Metric	-	-	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	0.002	0.04	24 inch, 600 mm	Yes	-	-	Vertical	Inch/Metric	-	-	Unlimited	-	Yes	-	Yes	-	-	1 pieces
Data sheet	0.0025	0.06	32 inch, 800 mm	Yes	-	-	Vertical	Inch/Metric	-	-	Unlimited	-	Yes	-	Yes	-	-	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

276.00 € ( 328.44 € )	5 working days
289.00 € ( 343.91 € )	5 working days
438.16 € ( 521.41 € )	5 working days
588.00 € ( 699.72 € )	60 working days
333.00 € ( 396.27 € )	5 working days
588.00 € ( 699.72 € )	5 working days
352.00 € ( 418.88 € )	5 working days
481.58 € ( 573.08 € )	60 working days
379.00 € ( 451.01 € )	5 working days
797.37 € ( 948.87 € )	60 working days
463.16 € ( 551.16 € )	5 working days
481.58 € ( 573.08 € )	5 working days
498.68 € ( 593.43 € )	5 working days
797.37 € ( 948.87 € )	60 working days
678.95 € ( 807.95 € )	5 working days
599.00 € ( 712.81 € )	5 working days
875.00 € ( 1,041.25 € )	5 working days
993.42 € ( 1,182.17 € )	5 working days
853.00 € ( 1,015.07 € )	5 working days
989.00 € ( 1,176.91 € )	60 working days
1,849.00 € ( 2,200.31 € )	5 working days
678.95 € ( 807.95 € )	60 working days
788.16 € ( 937.91 € )	60 working days
875.00 € ( 1,041.25 € )	60 working days
993.42 € ( 1,182.17 € )	60 working days
1,122.37 € ( 1,335.62 € )	5 working days
1,301.32 € ( 1,548.57 € )	5 working days
2,165.79 € ( 2,577.29 € )	60 working days
2,432.89 € ( 2,895.14 € )	60 working days
516.00 € ( 614.04 € )	5 working days
788.16 € ( 937.91 € )	5 working days
875.00 € ( 1,041.25 € )	5 working days
993.42 € ( 1,182.17 € )	5 working days
1,122.37 € ( 1,335.62 € )	60 working days
989.00 € ( 1,176.91 € )	5 working days
2,165.79 € ( 2,577.29 € )	60 working days
2,432.89 € ( 2,895.14 € )	60 working days
678.95 € ( 807.95 € )	60 working days
788.16 € ( 937.91 € )	60 working days
875.00 € ( 1,041.25 € )	60 working days
993.42 € ( 1,182.17 € )	60 working days
1,122.37 € ( 1,335.62 € )	5 working days
1,301.32 € ( 1,548.57 € )	5 working days
2,165.79 € ( 2,577.29 € )	60 working days
2,432.89 € ( 2,895.14 € )	60 working days
516.00 € ( 614.04 € )	5 working days
599.00 € ( 712.81 € )	5 working days
665.00 € ( 791.35 € )	60 working days
755.00 € ( 898.45 € )	5 working days
1,122.37 € ( 1,335.62 € )	5 working days
989.00 € ( 1,176.91 € )	5 working days
1,646.00 € ( 1,958.74 € )	60 working days
1,849.00 € ( 2,200.31 € )	5 working days
678.95 € ( 807.95 € )	60 working days
788.16 € ( 937.91 € )	60 working days
875.00 € ( 1,041.25 € )	5 working days
993.42 € ( 1,182.17 € )	5 working days
1,122.37 € ( 1,335.62 € )	5 working days
1,301.32 € ( 1,548.57 € )	5 working days
2,165.79 € ( 2,577.29 € )	60 working days

Basic information

Basic information

This unit has an ABSOLUTE capacitive-type scale.
- The ZERO point is set only once and is stored as the absolute ZERO point until the next battery replacement.
- The display has large characters, making it easy to read.
- Diameter measurement function is included.
