NORELEM

Bevel gears, plastic, ratio 1:4 injection-moulded, straight teeth, engagement angle 20° (22432)

Bevel gears, plastic, ratio 1:4 injection-moulded, straight teeth, engagement angle 20° (22432)

Part number:

Still undefined. 12 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    22432-110140010
    22432-110140040
    22432-115140010
    22432-115140040
    22432-120140010
    22432-120140040
    22432-210140010
    22432-210140040
    22432-215140010
    22432-215140040
    22432-220140010
    22432-220140040

    Module

    Number of Teeth

    (Teeth)

    Width

    (mm)

    Main material

    D

    (mm)

    D1=Pitch circle diameter

    (mm)

    D2

    (mm)

    D3=Thread

    A

    (mm)

    A1

    (mm)

    B

    (mm)

    L1

    (mm)

    L2

    (mm)

    Max. Torque

    (Ncm)

    Weight (ERP)

    (kg)

    		Minimum order quantity
    1
    10
    17.7
    Polyacetal
    12
    10
    7.9
    4
    30.2
    -
    8
    9.6
    -
    10
    0.0010
    1 pieces
    1
    40
    16.9
    Polyacetal
    41
    40
    23.4
    10
    -
    20.2
    8.4
    10.8
    15.5
    42.2
    0.0125
    1 pieces
    1.5
    10
    23.2
    Polyacetal
    18
    15
    11.3
    5
    41.5
    -
    12.2
    11
    -
    34.5
    0.0030
    1 pieces
    1.5
    40
    21
    Polyacetal
    60.7
    60
    30.4
    12
    -
    25.2
    12.3
    12.8
    19
    139.1
    0.0316
    1 pieces
    2
    10
    28.7
    Polyacetal
    23.7
    20
    14
    6
    53.5
    -
    16
    12.8
    -
    80.4
    0.0061
    1 pieces
    2
    40
    27
    Polyacetal
    81.2
    80
    36.1
    18
    -
    32.5
    16.2
    17
    24.4
    325.7
    0.0617
    1 pieces
    1
    10
    17.7
    Polyketone
    12
    10
    7.9
    4
    30.2
    -
    8
    9.6
    -
    10.5
    0.0008
    1 pieces
    1
    40
    16.9
    Polyketone
    41
    40
    23.4
    10
    -
    20.2
    8.4
    10.8
    15.5
    44.3
    0.0111
    1 pieces
    1.5
    10
    23.2
    Polyketone
    18
    15
    11.3
    5
    41.5
    -
    12.2
    11
    -
    36.2
    0.0026
    1 pieces
    1.5
    40
    21
    Polyketone
    60.7
    60
    30.4
    12
    -
    25.2
    12.3
    12.8
    19
    146
    0.0277
    1 pieces
    2
    10
    28.7
    Polyketone
    23.7
    20
    14
    6
    53.5
    -
    16
    12.8
    -
    84.4
    0.0055
    1 pieces
    2
    40
    27
    Polyketone
    81.2
    80
    36.1
    18
    -
    32.5
    16.2
    17
    24.4
    342
    0.0980
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    1.12 €
    ( 1.33 € )
    4 working days
    4.37 €
    ( 5.20 € )
    4 working days
    1.68 €
    ( 2.00 € )
    4 working days
    6.72 €
    ( 8.00 € )
    4 working days
    2.87 €
    ( 3.42 € )
    4 working days
    11.55 €
    ( 13.74 € )
    4 working days
    1.35 €
    ( 1.61 € )
    4 working days
    5.33 €
    ( 6.34 € )
    4 working days
    2.03 €
    ( 2.42 € )
    4 working days
    8.06 €
    ( 9.59 € )
    4 working days
    3.46 €
    ( 4.12 € )
    4 working days
    13.92 €
    ( 16.56 € )
    4 working days
  • 1

    • More Information

    Basic information

    · High hardness

    · Lower coefficient of friction

    · Long service life

    · High security against tooth breakage
