8 Series (Groove Width 10 mm) - for 2-Row Grooves - Extruded Extra Thick Bracket, 8-Mounting Hole Type

• CatalogP.2-650

• Outline drawing and specifications table
• Part number list
• More Information
• Catalog

Outline drawing and specifications table

Type	Material	Surface Treatment
NBLUDW8	EN AW-6063-T5 Equiv.	Anodize
HBLUDW8	EN AC-51400-T5 Equiv.

Specifications

Part Number

HBLTD8

Part Number	Mass (g)	Applicable Screw, T Nut				Allowable Load (N)	Unit Price	Volume Discount Rate
		Screw	Quantity	T Nut	Quantity		1~99 pc(s).	100~200
NBLUDW8	332	CBM8-15	4	HNTT8-8	8	5586
		CBM8-25
HBLUDW8	332	CBM8-15	4	HNTT8-8	8	5586
		CBM8-25

Alterations

Part number list

Number of items

30 items60 items90 items

1

Part number

HBLUDW8

HBLUDW8-C

HBLUDW8-C-SEP

HBLUDW8-C-SET

HBLUDW8-C-SEU

HBLUDW8-C-SSP

HBLUDW8-C-SST

HBLUDW8-C-SSU

HBLUDW8-SEP

HBLUDW8-SET

HBLUDW8-SEU

HBLUDW8-SSP

HBLUDW8-SST

HBLUDW8-SSU

NBLUDW8

NBLUDW8-C

NBLUDW8-C-SEP

NBLUDW8-C-SET

NBLUDW8-C-SEU

NBLUDW8-C-SSP

NBLUDW8-C-SST

NBLUDW8-C-SSU

NBLUDW8-SEP

NBLUDW8-SET

NBLUDW8-SEU

NBLUDW8-SSP

NBLUDW8-SST

NBLUDW8-SSU

Material	Cover Mounting Hole Addition Work	Accessories	RoHS?	Minimum order quantity

EN AC-51400-T5 Equiv.	Not Provided	Not Provided	10	1 pieces
EN AC-51400-T5 Equiv.	C (Tap for Cover Mounting)	Not Provided	10	1 pieces
EN AC-51400-T5 Equiv.	C (Tap for Cover Mounting)	SEP (Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	C (Tap for Cover Mounting)	SET (Screw, Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	C (Tap for Cover Mounting)	SEU (Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	C (Tap for Cover Mounting)	SSP (Stainless Steel Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	C (Tap for Cover Mounting)	SST (Stainless Steel Screw and Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	C (Tap for Cover Mounting)	SSU (Stainless Steel Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	Not Provided	SEP (Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	Not Provided	SET (Screw, Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	Not Provided	SEU (Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	Not Provided	SSP (Stainless Steel Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	Not Provided	SST (Stainless Steel Screw and Nut Set)	-	1 pieces
EN AC-51400-T5 Equiv.	Not Provided	SSU (Stainless Steel Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AW-6063-T5 Equiv.	Not Provided	Not Provided	10	1 pieces
EN AW-6063-T5 Equiv.	C (Tap for Cover Mounting)	Not Provided	10	1 pieces
EN AW-6063-T5 Equiv.	C (Tap for Cover Mounting)	SEP (Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AW-6063-T5 Equiv.	C (Tap for Cover Mounting)	SET (Screw, Nut Set)	-	1 pieces
EN AW-6063-T5 Equiv.	C (Tap for Cover Mounting)	SEU (Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AW-6063-T5 Equiv.	C (Tap for Cover Mounting)	SSP (Stainless Steel Screw, Post-Assembly Insertion Spring Nut Set)	10	1 pieces
EN AW-6063-T5 Equiv.	C (Tap for Cover Mounting)	SST (Stainless Steel Screw and Nut Set)	10	1 pieces
EN AW-6063-T5 Equiv.	C (Tap for Cover Mounting)	SSU (Stainless Steel Screw, Pre-Assembly Insertion Spring Nut Set)	10	1 pieces
EN AW-6063-T5 Equiv.	Not Provided	SEP (Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AW-6063-T5 Equiv.	Not Provided	SET (Screw, Nut Set)	-	1 pieces
EN AW-6063-T5 Equiv.	Not Provided	SEU (Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
EN AW-6063-T5 Equiv.	Not Provided	SSP (Stainless Steel Screw, Post-Assembly Insertion Spring Nut Set)	10	1 pieces
EN AW-6063-T5 Equiv.	Not Provided	SST (Stainless Steel Screw and Nut Set)	10	1 pieces
EN AW-6063-T5 Equiv.	Not Provided	SSU (Stainless Steel Screw, Pre-Assembly Insertion Spring Nut Set)	10	1 pieces

Unit price (excluding VAT)(Unit price including VAT) Sort by	Standard shipping days Sort by

11.06 € ( 13.16 € )	Stock item: 1 working dayAvailable for same-day shipping
11.45 € ( 13.63 € )	5 working days
18.34 € ( 21.82 € )	5 working days
17.04 € ( 20.28 € )	Stock item: 1 working dayAvailable for same-day shipping
18.34 € ( 21.82 € )	Stock item: 1 working dayAvailable for same-day shipping
19.57 € ( 23.29 € )	Stock item: 1 working dayAvailable for same-day shipping
17.55 € ( 20.88 € )	Stock item: 1 working dayAvailable for same-day shipping
21.67 € ( 25.79 € )	Stock item: 1 working dayAvailable for same-day shipping
17.97 € ( 21.38 € )	5 working days
16.66 € ( 19.83 € )	5 working days
17.97 € ( 21.38 € )	5 working days
19.18 € ( 22.82 € )	5 working days
17.16 € ( 20.42 € )	5 working days
21.30 € ( 25.35 € )	5 working days
9.95 € ( 11.84 € )	5 working days
10.33 € ( 12.29 € )	5 working days
17.23 € ( 20.50 € )	5 working days
15.92 € ( 18.94 € )	5 working days
17.23 € ( 20.50 € )	5 working days
18.44 € ( 21.94 € )	5 working days
16.42 € ( 19.54 € )	5 working days
20.55 € ( 24.45 € )	5 working days
16.85 € ( 20.05 € )	5 working days
15.54 € ( 18.49 € )	5 working days
16.85 € ( 20.05 € )	5 working days
18.06 € ( 21.49 € )	5 working days
16.05 € ( 19.10 € )	5 working days
20.18 € ( 24.01 € )	5 working days

1

More Information

• Basic information

Basic information

It is a bracket that can connect a 2-row groove type frame with a single bracket.
