Thread grommets / external thread / short and long version
- Volume Discount
- Order quantities extended (D-JIT)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Drawing
- 3D Preview 3D preview is available after complete configuration
- Part Numbers
- Catalog
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Loading...
Part Number
|
|---|
| NPL1-50 |
| NPL1-100 |
| NPL1-150 |
| NPL2-50 |
| NPL2-100 |
| NPL2-150 |
| NPL3-50 |
| NPL3-100 |
| NPL3-150 |
| NPW1 |
| NPW2 |
| NPW3 |
| Part Number | Minimum order quantity | Volume Discount | R/(PT) (Nominal) | L (Length) (mm) | |
|---|---|---|---|---|---|
| 1 | Available | Quote | 1/8 | 50 | |
| 1 | Available | Quote | 1/8 | 100 | |
| 1 | Available | Quote | 1/8 | 150 | |
| 1 | Available | Quote | 1/4 | 50 | |
| 1 | Available | Quote | 1/4 | 100 | |
| 1 | Available | Quote | 1/4 | 150 | |
| 1 | Available | Quote | 3/8 | 50 | |
| 1 | Available | Quote | 3/8 | 100 | |
| 1 | Available | Quote | 3/8 | 150 | |
| 1 | Available | Quote | 1/8 | 38 | |
| 1 | Available | Quote | 1/4 | 38 | |
| 1 | Available | Quote | 3/8 | 48 |
Loading...
Basic information
| Material | Brass | Connecting parts | Hose | With/without valve | No valve |
|---|---|---|---|---|---|
| Shape | Straight | Spanner installation section | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
