Internal Gear IS
- Promotional pricing
- Volume Discount
Small module internal gear for module 0.5 / 0.8 / 1.0.
Outer diameter tolerance is finished to h8, and it can be used as it is in the hole of the housing etc. Material: C3713P, C3604B, S45C.
Outer diameter tolerance is finished to h8, and it can be used as it is in the hole of the housing etc. Material: C3713P, C3604B, S45C.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
IS50B80A-0360
Basic information
| Module | 0.5 | Material | EN CW614N Equiv. / C3713P | The Number of Teeth(Teeth) | 80 |
|---|---|---|---|---|---|
| Reference diameter(mm) | 40 | Tip Dia.(mm) | 39 | Face Width(mm) | 3 |
| Outer Diameter, Hub Outside Diameter(mm) | 60 | Pilot Hole Product, Completed Product | Finished product | Shaft hole finished | Internal Gear |
This page is Internal Gear IS, part number IS50B80A-0360.
You can find the detail information about specifications and dimensions on part number IS50B80A-0360.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
