Confirmed
- Allowable Load(Range Specification)(N)
- Allowable Load P2(N)
- 34.52
- Length L2 in Allowable Load(mm)
- 104.6
- Free Length Lf(mm)
- 65.3
- Outer Diameter OD(mm)
- 10
- Initial Tension Pi(N)
- 8.826
- Spring Constant K(N/mm)
- 0.653
- Load Length L1(mm)
- 85
- Reference load P1(N)
- 21.67
- Coil Center Diameter D(Ø)
- 8.8
- Wire diameter d(Ø)
- 1.2
- Total coils Nt
- 39.5
- Maximum Elastic Curve Equation(mm)
- 39.3
- Type
- CAD
- 2D
- 3D
- Est. shipping days
- All
- Same-day shipping possible
UltraSpring Tension Coil Springs (E667)
Product information
More Information
Basic information
Standard springs that are produced by accurate quality control.
These springs are controlled by measuring loading at two points: allowable load and independently established standard load—in addition to the required dimensions.
All products have lot numbers and full traceability.
