Industrial Castors STC Series with Swivel Stopper (SW-4)
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| STC-125CBCSW-4 |
| STC-125CNCSW-4 |
| STC-150CBCSW-4 |
| STC-150NBSW-4 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Mounting Height H (mm) | Allowable Load (daN) | Wheel Material | Wheel Characteristics | Wheel Dia. D (mm) | Wheel Width B (mm) | Swivel Radius (mm) | Wheel Bearings | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
65.09 € | 1 | 11 Days | 10 | 165 | 150 | [Synthetic Rubber] Rubber | NA | 125 | 38 | 118 | Available | ||
59.65 € | 1 | Available | 8 Days | 10 | 165 | 150 | [Synthetic Rubber] Rubber | NA | 125 | 38 | 118 | NA | |
69.72 € | 1 | 8 Days | 10 | 190 | 160 | [Synthetic Rubber] Rubber | NA | 150 | 40 | 122 | Available | ||
76.92 € | 1 | 8 Days | 10 | 190 | 160 | [Nylon] Nylon, White | Oil Resistance | 150 | 35 | 122 | Available |
Loading...
Basic information
| Caster Type | Plate Type Universal | Load Range(daN) | 140.01~220.00 | Stopper | With Double Stopper (Rotation + Turning) |
|---|---|---|---|---|---|
| Fitting Material | Steel | Mounting Hole Type | Long Hole | Mounting Hole Pitch, Long Length Direction L1(mm) | 75(80) |
| Mounting Hole Pitch, Short Length Direction W1(mm) | 75(80) | Plate Length L(mm) | 102 | Plate Width W(mm) | 102 |
| Application | Commercial Facilities/Displays/Product Stands / Distribution/Hand Truck/Pallet / Steel/Woodwork Furniture / Factory facilities / Vertical lift | Load Category | Medium Load | Combination of Slotted Hole Pitch | 75-75, 76-76, 77-77, 78-78, 79-79, 80-80 |
| Stopper Type | SW-4 |
Configure
Basic Attributes
-
Mounting Height H(mm)
-
Allowable Load(daN)
-
Wheel Material
- Synthetic Rubber
- Nylon
- Synthetic Rubber
-
Wheel Characteristics
- Oil Resistance
- NA
-
Wheel Dia. D(mm)
-
Wheel Width B(mm)
-
Swivel Radius(mm)
-
Wheel Bearings
- Available
- NA
-
Type
- STC-SW-4
-
Filter by CAD data type
- 2D
Filter by standard shipping days
-
- All
- 8 Days or Less
- 11 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
