NIHON PISCO

Vacuum Pad Oval Small Type VPMB Barb Fitting Type

Vacuum Pad Oval Small Type VPMB Barb Fitting Type

Part number:

Still undefined. 44 possible part numbers found.
Quantity:

Product information

Dimensions

Vacuum Pad Oval Small Type VPMB Barb Fitting Type

Standard table

Model codePad size
X		Pad size
Y		Tube I.D.
øD		ECConnection
config. code
VPMB4×10E[5]-3B[9]410213.46-M6
VPMB4×10E[5]-4B[9]2.514.97
VPMB4×10E[5]-6B[9]4
VPMB4×20E[5]-3B[9]20213.46
VPMB4×20E[5]-4B[9]2.514.97
VPMB4×20E[5]-6B[9]4
VPMB4×30E[5]-3B[9]30213.46
VPMB4×30E[5]-4B[9]2.514.97
VPMB4×30E[5]-6B[9]4
VPMB5×10E[5]-3B[9]510213.46
VPMB5×10E[5]-4B[9]2.514.97
VPMB5×10E[5]-6B[9]4
VPMB5×20E[5]-3B[9]20213.46
VPMB5×20E[5]-4B[9]2.514.97
VPMB5×20E[5]-6B[9]4
VPMB5×30E[5]-3B[9]30213.46
VPMB5×30E[5]-4B[9]2.514.97
VPMB5×30E[5]-6B[9]4
VPMB6×10E[5]-3B[9]610213.46
VPMB6×10E[5]-4B[9]2.514.97
VPMB6×10E[5]-6B[9]4
VPMB6×20E[5]-3B[9]20213.46
VPMB6×20E[5]-4B[9]2.514.97
VPMB6×20E[5]-6B[9]4
VPMB6×30E[5]-3B[9]30213.46
VPMB6×30E[5]-4B[9]2.514.97
VPMB6×30E[5]-6B[9]4
VPMB8×20E[5]-3B[9]820213.46
VPMB8×20E[5]-4B[9]2.514.97
VPMB8×20E[5]-6B[9]4
VPMB8×30E[5]-3B[9]30213.46
VPMB8×30E[5]-4B[9]2.514.97
VPMB8×30E[5]-6B[9]4

Units: mm

*[5]: Replaced with Pad rubber material code. Refer to the catalog for details.
*[9]: Replaced with "-S3" for -S3 spec. (Copper alloy free material for metal parts and FKM or HNBR for sealing parts).
*Pad material N and NE are not suitable for use under ozone environment.
