Connector, Male Unit, Elbow
[Features] It is a connector that allows to connect and disconnect several pipes at the same time.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| PQ3ML-A |
| PQ4ML-A |
| PQ6L-A |
| PQ6ML-A |
| PQ8L-A |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Tube O.D. (mm) D (mm) | Main Unit Type | |
|---|---|---|---|---|---|---|
3.94 € | 1 | 10 Days | 3 | Mini Type Elbow | ||
3.94 € | 1 | 10 Days | 4 | Mini Type Elbow | ||
4.09 € | 1 | 11 Days | 6 | Standard Type Elbow | ||
4.01 € | 1 | 10 Days | 6 | Mini Type Elbow | ||
4.42 € | 1 | 11 Days | 8 | Standard Type Elbow |
Loading...
Basic information
| Type | Multi | Joint Type | With One-Touch Couplings | Male/Female | Plug (Male) |
|---|---|---|---|---|---|
| Main Body Material | Resin | Seal Material | NBR | Applicable Fluid | Air |
| Valve Structure | Double passages opening type | Usage Environment/Application | Standard / Vacuum / Industrial Machinery | Operating Temperature Range(℃) | 0::60 |
| Operating Pressure Range(MPa) | 0::0.9 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
