Single Unit Type, Type B Union Straight for Granular / Powder Body Transport
[Features]
· Transports small indefinite shaped working material such as granules, powder and fiber.
· A vacuum (intake) port and exhaust port are in a single line, and by expelling the working material from the vacuum port through the interior of the vacuum generator VRL, the working material can be transported through the tube.
· Allows model selection by size and weight of working material.
· Transports small indefinite shaped working material such as granules, powder and fiber.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| VRL50-060108 |
| VRL50-080108 |
| VRL100-120212 |
| VRL200-160216 |
| VRL300-160216 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Air Consumption Flow Rate (l/min) | Vacuum Port One-Touch Fitting Size | Air Supply Port Connecting Port Shape | Suction Flow (l/min) | Size of Exhaust One-Touch Couplings | |
|---|---|---|---|---|---|---|---|---|---|
62.48 € | 1 | 5 Days | 50 | φ6 | R1/8 | 50 | φ8 | ||
62.46 € | 1 | 12 Days | 50 | φ8 | R1/8 | 50 | φ8 | ||
84.94 € | 1 | 5 Days | 100 | φ12 | R1/4 | 100 | φ12 | ||
106.54 € | 1 | 10 Days | 200 | φ16 | R1/4 | 200 | φ16 | ||
125.65 € | 1 | 10 Days | 300 | φ16 | R1/4 | 300 | φ16 |
Loading...
Basic information
| Type | Ring Blow Type Union Straight B | Additional Function | Valve for Vacuum Generation | Ultimate Vacuum(kPa) | -53 |
|---|---|---|---|---|---|
| Vacuum Port Connecting Port Shape | Single-Action Coupling | Application | Single Item | Operating Pressure Range(MPa) | 0::0.9 |
| Operating Temperature Range(°C) | 0::60 | Shape of Exhaust Connection Port | Single-Action Coupling |
Configure
Basic Attributes
-
Air Consumption Flow Rate(l/min)
-
Vacuum Port One-Touch Fitting Size
-
Air Supply Port Connecting Port Shape
- R1/8
- R1/4
-
Suction Flow(l/min)
-
Size of Exhaust One-Touch Couplings
- φ8
- φ12
- φ16
-
Type
- VRL
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 5 Days or Less
- 10 Days or Less
- 12 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
