JK-S Swivel Wheel (Swivel Rigid Type) Plate Type
- Promotional pricing ends 30/11/2024
- Volume Discount
- Stock
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| GUJK-150S |
| UWJK-150S |
| WJK-150S |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Load Range (daN) | Allowable Load (daN) | Wheel Material | Wheel Characteristics | Wheel Width (mm) | |
|---|---|---|---|---|---|---|---|---|---|
72.42 € | 1 | 5 Days | 140.01~220.00 | 200 | [Others] Nylon Foil Urethane Foam | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | 40 | ||
63.16 € 44.21 € | 1 | Available |
Same day
Stock | 220.01~320.00 | 300 | [Urethane] Urethane | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | 38 | |
61.14 € | 1 | 5 Days | 140.01~220.00 | 200 | Rubber | NA | 40 |
Loading...
Basic information
| Caster Type | Plate Type Universal | Mounting Height H(mm) | 198 | Stopper | With Double Stopper (Rotation + Turning) |
|---|---|---|---|---|---|
| Fitting Material | Steel | Mounting Hole Type | Long Hole | Mounting Hole Pitch, Long Length Direction L1(mm) | 87(94) |
| Mounting Hole Pitch, Short Length Direction W1(mm) | 87(94) | Plate Length(mm) | 120 | Plate Width(mm) | 120 |
| Wheel Dia. D(mm) | 150 | Application | Streamlining of Logistics, Hand Truck / Factory facilities / Vertical lift | Swivel Radius(mm) | 115 |
| Load Category | Heavy Load | Combination of Slotted Hole Pitch | 87-87, 88-88, 89-89, 90-90, 91-91, 92-92, 93-93, 94-94 | Stopper | Available |
| Wheel Bearings | Available |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Load Range(daN)
- 140.01~220.00
- 220.01~320.00
-
Allowable Load(daN)
-
Wheel Material
- Rubber
- Urethane
- Others
-
Wheel Characteristics
- Abrasion Resistance
- Gasoline Resistance (Light Oil included)
- Oil Resistance
- NA
-
Wheel Width(mm)
-
Type
- GUJK-S
- UWJK-S
- WJK-S
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
Optional Attributes
- There is a 10% discount on the price per unit at 20 or more items.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
