Stainless Steel Low Floor Castors for Heavy Loads SUHJ
[Features]
· A sealed type stainless steel radial ball bearing is used for the wheel that provides quiet and smooth rotation without the need for grease to be added.
· Stainless steel 304 is used for the hardware (including the swivel part ball) and the bearing.
· The swivel part is equipped with a light working bilayer bearing that includes a dust-proof cover.
· Turning is smooth even after withstanding loads for long periods of time.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| SUHJ-50-MC |
| SUHJ-50-YN |
| SUHJ-65-MC |
| SUHJ-65-YN |
| SUHJ-75-MC |
| SUHJ-75-YN |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Mounting Height H (mm) | Load Range (daN) | Allowable Load (daN) | Wheel Material | Wheel Characteristics | Mounting Hole Pitch Length (mm) | Mounting Hole Pitch Width (mm) | Mounting SeatLength (mm) | Mounting Seat Width (mm) | Wheel Diameter (mm) | Rim Width (mm) | Detailed Wheel Specifications | Wheel color | Eccentricity (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
80.24 € | 1 | 10 Days | 78 | 220.01~320.00 | 294 | [Nylon] Monomer Casting Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance | 55(65) | 55(65) | 82 | 82 | 50 | 32.5 | Oil Resistance | Blue | 18 | ||
77.59 € | 1 | 9 Days | 78 | 220.01~320.00 | 294 | [Nylon] Nylon 6 | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | 55(65) | 55(65) | 82 | 82 | 50 | 32.5 | Core: None | Black | 18 | ||
106.52 € | 1 | 9 Days | 96.5 | 320.01~485.00 | 392 | [Nylon] Monomer Casting Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance | 63(78) | 63(78) | 100 | 100 | 65 | 36 | Oil Resistance | Blue | 22 | ||
102.43 € | 1 | 9 Days | 96.5 | 320.01~485.00 | 392 | [Nylon] Nylon 6 | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | 63(78) | 63(78) | 100 | 100 | 65 | 36 | Core: None | Black | 22 | ||
111.83 € | 1 | 9 Days | 108 | 485.01~750.00 | 490 | [Nylon] Monomer Casting Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance | 63(78) | 63(78) | 100 | 100 | 75 | 39 | Oil Resistance | Blue | 25 | ||
107.81 € | 1 | 10 Days | 108 | 485.01~750.00 | 490 | [Nylon] Nylon 6 | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | 63(78) | 63(78) | 100 | 100 | 75 | 39 | Core: None | Black | 25 |
Loading...
Basic information
| Caster Type | Plate Type Universal / Low Floor Heavy Load | Stopper | NA | Fitting Material | Stainless Steel |
|---|---|---|---|---|---|
| Mounting Hole Type | Long Hole | Application | OA equipment, information and communication equipment / Factory facilities | Load Category | Heavy Load |
| Metal Fitting Color (Finish) | NA | Specifications | The wheels on earth | Floor Protection | No Floor Protection |
| Bearing | Stainless Radial Ball Bearing |
Configure
Basic Attributes
-
Mounting Height H(mm)
-
Load Range(daN)
- 220.01~320.00
- 320.01~485.00
- 485.01~750.00
-
Allowable Load(daN)
-
Wheel Material
- Nylon
- Nylon
-
Wheel Characteristics
- Abrasion Resistance
- Gasoline Resistance (Light Oil included)
- Oil Resistance
- Chemical Resistance
-
Mounting Hole Pitch Length(mm)
-
Mounting Hole Pitch Width(mm)
-
Mounting SeatLength(mm)
-
Mounting Seat Width(mm)
-
Wheel Diameter(mm)
-
Rim Width(mm)
-
Detailed Wheel Specifications
-
Wheel color
- Black
- Blue
-
Eccentricity(mm)
- 18
- 22
- 25
-
Type
- SUHJ
-
Filter by CAD data type
- 2D
Filter by standard shipping days
-
- All
- 9 Days or Less
- 10 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
