Robo Dimensional Turn Stage Type III
Multi-purpose variable stand on which devices such as optical devices and machining jigs can be mounted.
[Features]
· Rotating stage, with tilting of ±90°.
· Etched scale with numerals for every 2.5°.
· Socket and spigot processing to also take care of impact load.
· Thread locking, W nut specifications.
· Tightening screw for temporary fastening.
· With handle and screw sold separately.
[Features]
· Rotating stage, with tilting of ±90°.
· Etched scale with numerals for every 2.5°.
· Socket and spigot processing to also take care of impact load.
· Thread locking, W nut specifications.
· Tightening screw for temporary fastening.
· With handle and screw sold separately.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
MBR45-300R
- Product data
- CAD data not available
Basic information
| Dimension L(mm) | 90 | Dimension H(mm) | 15 | Pitch P(mm) | 25 |
|---|---|---|---|---|---|
| F(mm) | 60 | G(N) | 80 | Load Resistance | 70 |
This page is Robo Dimensional Turn Stage Type III, part number MBR45-300R.
You can find the detail information about specifications and dimensions on part number MBR45-300R.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
