Profile Handle (W5-30)
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Pitch P (mm) | Screw-on distance A (mm) | Length L (mm) | Surface treatment | Handle color | |
|---|---|---|---|---|---|---|---|---|---|---|
58.78 € | 1 | Available | 12 Days | 10 | 200 | 200 | 250 | Anodized | Shank black ledge silver | |
61.12 € | 1 | Available | 12 Days | 10 | 200 | 200 | 250 | Anodized | Shank and ledge black | |
61.12 € | 1 | Available | 12 Days | 10 | 200 | 200 | 250 | Powder-coated | Shank and ledge black | |
60.06 € | 1 | Available | 12 Days | 10 | 250 | 250 | 300 | Anodized | Shank black ledge silver | |
62.52 € | 1 | Available | 12 Days | 10 | 250 | 250 | 300 | Anodized | Shank and ledge black | |
62.52 € | 1 | Available | 12 Days | 10 | 250 | 250 | 300 | Powder-coated | Shank and ledge black | |
61.48 € | 1 | Available | 12 Days | 10 | 300 | 300 | 350 | Anodized | Shank black ledge silver | |
63.96 € | 1 | Available | 12 Days | 10 | 300 | 300 | 350 | Anodized | Shank and ledge black | |
63.96 € | 1 | Available | 12 Days | 10 | 300 | 300 | 350 | Powder-coated | Shank and ledge black | |
62.92 € | 1 | Available | 12 Days | 10 | 350 | 350 | 400 | Anodized | Shank black ledge silver | |
65.38 € | 1 | Available | 12 Days | 10 | 350 | 350 | 400 | Anodized | Shank and ledge black | |
65.38 € | 1 | Available | 12 Days | 10 | 350 | 350 | 400 | Powder-coated | Shank and ledge black | |
64.24 € | 1 | Available | 12 Days | 10 | 400 | 400 | 450 | Anodized | Shank black ledge silver | |
66.80 € | 1 | Available | 12 Days | 10 | 400 | 400 | 450 | Anodized | Shank and ledge black | |
66.80 € | 1 | Available | 12 Days | 10 | 400 | 400 | 450 | Powder-coated | Shank and ledge black | |
66.98 € | 1 | Available | 12 Days | 10 | 500 | 500 | 550 | Anodized | Shank black ledge silver | |
69.68 € | 1 | Available | 12 Days | 10 | 500 | 500 | 550 | Anodized | Shank and ledge black | |
69.68 € | 1 | Available | 12 Days | 10 | 500 | 500 | 550 | Powder-coated | Shank and ledge black | |
69.72 € | 1 | Available | 12 Days | 10 | 600 | 600 | 650 | Anodized | Shank black ledge silver | |
72.50 € | 1 | Available | 12 Days | 10 | 600 | 600 | 650 | Anodized | Shank and ledge black | |
72.50 € | 1 | Available | 12 Days | 10 | 600 | 600 | 650 | Powder-coated | Shank and ledge black |
Loading...
Basic information
| Main Body Type | Surfaced Type | Surfaced Type Category | U Shape | U-shaped Type | Straight |
|---|---|---|---|---|---|
| Main Body Material | Aluminum | Height H(mm) | 66.5 | Applied Load(N) | 1000 |
| Main Body, Surface Treatment | Powder Coating | Mounting Method | Tapped | Handle Thickness D(mm) | 30 |
| Handle Cross Sectional Shape | Round Shape | Fastening M | M8 | Material | AlMgSi 0.5, PA6 |
Configure
Basic Attributes
-
Pitch P(mm)
-
Screw-on distance A(mm)
-
Length L(mm)
-
Surface treatment
- Anodized
- Powder-coated
-
Handle color
- Shank and ledge black
- Shank black ledge silver
-
Type
- W5-30ZZZ
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 12 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
