M5HL, Miniature Fitting - Hose Elbow
[Features]
· Compact piping space.
· Rotates 360° around the stud as an axis, allowing it to be fixed at any angle.
· Small and can be removed without tools.
(i)Remark
- Refer to the catalog for product specifications.
- Product images may be representative images. Refer to the catalog for details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| M-5HL-4 |
| M-5HL-4-X83 |
| M-5HL-4-X112 |
| M-5HL-6 |
| M-5HL-6-X83 |
| M-5HL-6-X112 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Material | Applicable tube material (O.D./I.D.) | Gasket Material | Made to Order Specifications | Screw Pitch (mm) | |
|---|---|---|---|---|---|---|---|---|---|
3.40 € | 10 |
Same day
Stock | [Resin] 00014 | Nylon・Soft Nylon・Polyurethane (4/2.5) | Nylon 66・GF30% | N/A | - | ||
3.23 € | 10 | 26 Days | [Copper] C3604BD | - | - | - | 0.8 | ||
5.53 € | 10 | 26 Days | [Copper] C3604BD | - | SUS316 + Special FKM | - | 0.8 | ||
3.40 € | 10 |
Same day
Stock | [Resin] 00014 | Nylon・Soft Nylon・Polyurethane (6/4) | Nylon 66・GF30% | N/A | - | ||
3.23 € | 10 | 26 Days | [Copper] C3604BD | - | - | - | 0.8 | ||
5.53 € | 10 | 26 Days | [Copper] C3604BD | - | SUS316 + Special FKM | - | 0.8 |
