RE.C7-G - Twin wheels for the general public -Vulcanised rubber coating
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 452002 |
| 452010 |
| 452050 |
| 452052 |
| 452152 |
| 452160 |
| 452202 |
| 452210 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | H (mm) | s (mm) | B (mm) | L (mm) | D (mm) | l3 (mm) | b1 | b2 | b3 | Diameter | d | d1 | l1 | l2 | R | p | Dynamic carrying capacity unit (N) | Description | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
13.60 € | 12 | Available | 4 Days | 70 | 6 | 60 | 60 | 50 | 18 | 38.5 | 48 | 30 | 50 | - | - | 38.5 | 48 | - | - | 600 | RE.C7-050-SBL-G | |
21.43 € | 12 | Available | 4 Days | 100 | 6 | 60 | 60 | 75 | 24 | 38.5 | 48 | 33 | 75 | - | - | 38.5 | 48 | - | - | 800 | RE.C7-075-SBL-G | |
26.53 € | 12 | Available | 4 Days | 100 | 6 | 60 | 60 | 75 | 24 | 38.5 | 48 | 33 | 75 | - | - | 38.5 | 48 | 95 | - | 800 | RE.C7-075-SBF-G | |
18.59 € | 12 | Available | 4 Days | 70 | 6 | 60 | 60 | 50 | 18 | 38.5 | 48 | 30 | 50 | - | - | 38.5 | 48 | 82 | - | 600 | RE.C7-050-SBF-G | |
13.75 € | 12 | Available | 4 Days | 70 | - | - | - | 50 | 18 | - | - | 30 | 50 | M10 | 42 | - | - | - | 15 | 600 | RE.C7-050-CBL-G | |
21.63 € | 12 | Available | 4 Days | 100 | - | - | - | 75 | 24 | - | - | 33 | 75 | M12 | 52 | - | - | - | 25 | 800 | RE.C7-075-CBL-G | |
18.88 € | 12 | Available | 4 Days | 70 | - | - | - | 50 | 18 | - | - | 30 | 50 | M10 | 42 | - | - | 82 | 15 | 600 | RE.C7-050-CBF-G | |
26.62 € | 12 | Available | 4 Days | 100 | - | - | - | 75 | 24 | - | - | 33 | 75 | M12 | 52 | - | - | 95 | 25 | 800 | RE.C7-075-CBF-G |
Loading...
Basic information
| Bracket material | Steel | Carrying capacity | 0to1400N |
|---|
Configure
Basic Attributes
-
H(mm)
-
s(mm)
-
B(mm)
-
L(mm)
-
D(mm)
-
l3(mm)
-
b1
-
b2
- 48
-
b3
-
Diameter
-
d
- M10
- M12
-
d1
- 42
- 52
-
l1
-
l2
- 48
-
R
-
p
- 15
- 25
-
Dynamic carrying capacity unit(N)
-
Type
- 452
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 4 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
