Polyurethane leadership
・Tread type : crowned, cylindrical
・Tread material: Polyurethane
・Tread color: Brown
[Features]
・Roller is characterized by good damping properties and quiet running
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Wheel diameter (mm) | Wheel width (mm) | Load capacity dynamic (kg) | electrically conductive | Tread type | Weight (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|
5.68 € | 1 | 4 Days | 22 | 10 | 18 | - | cylindrical | 0.004 | ||
5.94 € | 1 | 4 Days | 25 | 10 | 20 | none | cylindrical | 0.008 | ||
6.12 € | 1 | 4 Days | 30 | 11 | 22 | none | cylindrical | 0.016 | ||
6.27 € | 1 | 4 Days | 30 | 11 | 22 | none | cylindrical | 0.018 | ||
6.74 € | 1 | 4 Days | 32 | 16 | 44 | none | cylindrical | 0.02 | ||
3.82 € | 1 | 4 Days | 35 | 11 | 40 | none | cylindrical | 0.018 | ||
7.49 € | 1 | 4 Days | 35 | 15 | 60 | none | cylindrical | 0.026 | ||
7.81 € | 1 | 20 Days | 38 | 11 | 40 | none | crowned | 0.021 | ||
9.56 € | 1 | 4 Days | 40 | 14 | 70 | none | cylindrical | 0.041 | ||
8.03 € | 1 | 4 Days | 40 | 14 | 70 | none | cylindrical | 0.04 | ||
10.06 € | 1 | 4 Days | 40 | 20 | 90 | none | cylindrical | 0.046 | ||
11.05 € | 1 | 20 Days | 42 | 14 | 70 | none | cylindrical | 0.038 | ||
6.49 € | 1 | 4 Days | 45 | 15 | 80 | none | cylindrical | 0.036 | ||
9.64 € | 1 | 4 Days | 50 | 12 | 70 | - | cylindrical | 0.044 | ||
10.23 € | 1 | 4 Days | 50 | 15 | 80 | none | cylindrical | 0.038 | ||
10.40 € | 1 | 4 Days | 50 | 15 | 100 | - | cylindrical | 0.053 | ||
10.53 € | 1 | 4 Days | 50 | 15 | 80 | none | cylindrical | 0.054 | ||
10.71 € | 1 | 4 Days | 50 | 18 | 100 | none | cylindrical | 0.06 | ||
12.82 € | 1 | 4 Days | 50 | 18 | 100 | none | cylindrical | 0.058 | ||
13.61 € | 1 | 4 Days | 50 | 18 | 110 | none | cylindrical | 0.058 | ||
14.08 € | 1 | 4 Days | 50 | 18 | 110 | none | cylindrical | 0.056 | ||
12.62 € | 1 | 4 Days | 50 | 25 | 115 | none | cylindrical | 0.07 | ||
12.42 € | 1 | 4 Days | 50 | 25 | 115 | none | cylindrical | 0.076 | ||
12.77 € | 1 | 20 Days | 55 | 20 | 115 | none | cylindrical | 0.074 | ||
15.15 € | 1 | 20 Days | 57 | 20 | 135 | none | cylindrical | 0.096 | ||
12.41 € | 1 | 4 Days | 60 | 15 | 110 | none | crowned | 0.066 | ||
13.18 € | 1 | 4 Days | 60 | 20 | 150 | none | cylindrical | 0.098 | ||
12.89 € | 1 | 4 Days | 60 | 20 | 150 | none | cylindrical | 0.104 | ||
13.60 € | 1 | 4 Days | 60 | 25 | 150 | none | cylindrical | 0.098 | ||
14.26 € | 1 | 4 Days | 60 | 25 | 150 | none | cylindrical | 0.114 | ||
11.69 € | 1 | 20 Days | 64 | 18 | 150 | none | cylindrical | 0.104 | ||
13.64 € | 1 | 4 Days | 65 | 15 | 130 | none | crowned | 0.076 | ||
17.53 € | 1 | 20 Days | 70 | 17 | 80 | none | - | 0.14 | ||
13.37 € | 1 | 4 Days | 70 | 25 | 200 | none | crowned | 0.166 | ||
14.19 € | 1 | 5 Days | 80 | 25 | 200 | none | cylindrical | 0.214 | ||
17.18 € | 1 | 4 Days | 90 | 20 | 195 | - | crowned | 0.222 | ||
25.56 € | 1 | 20 Days | 100 | 25 | 260 | - | cylindrical | 0.288 | ||
33.74 € | 1 | 4 Days | 120 | 25 | 270 | none | cylindrical | 1.31 |
Loading...
Basic information
| Wheel bearing | Ball-bearing | Tread material | Polyurethane | Tread color | Brown |
|---|---|---|---|---|---|
| Min. temperature resistance(° C) | -20 | Max. temperature resistance(° C) | 80 |
Configure
Basic Attributes
-
Wheel diameter(mm)
-
Wheel width(mm)
-
Load capacity dynamic(kg)
-
electrically conductive
- none
-
Tread type
- crowned
- cylindrical
Filter by standard shipping days
-
- All
- 4 Days or Less
- 5 Days or Less
- 20 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
