Polyamide door roller with ball bearing seat
[Specifications]
・Wheel bearing: Bearing seat
・Rim material: Polyamide
・Tread material: Polyamide
・Wheel diameter(mm): 60
・Wheel width(mm): 22.5
・Load capacity dynamic(kg): 40
・Weight(kg): 0.03
these door rollers are made of poylamide, with plain bore and edged groove
・Wheel bearing: Bearing seat
・Rim material: Polyamide
・Tread material: Polyamide
・Wheel diameter(mm): 60
・Wheel width(mm): 22.5
・Load capacity dynamic(kg): 40
・Weight(kg): 0.03
these door rollers are made of poylamide, with plain bore and edged groove
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
F060-17KS30X19.5
- Product data
- CAD data not available
Basic information
| Wheel diameter(mm) | 60 | Wheel width(mm) | 22.5 | Load capacity dynamic(kg) | 40 |
|---|---|---|---|---|---|
| Wheel bearing | Bearing seat | Surface coating | Without | Rim material | Polyamide |
| Tread material | Polyamide | Weight(kg) | 0.03 |
This page is Polyamide door roller with ball bearing seat, part number F060-17KS30X19.5.
You can find the detail information about specifications and dimensions on part number F060-17KS30X19.5.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
