TORWEGGE

Stainless steel swivel Castors with bolt hole attachment, polyamide wheel

Stainless steel swivel Castors with bolt hole attachment, polyamide wheel

Part number:

Still undefined. 2 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    L-AV-PAA-050-G-1
    L-AV-PAA-075-G-1

    Wheel diameter

    (mm)

    Wheel width

    (mm)

    Load capacity dynamic

    (kg)

    overall height

    (mm)

    Swivel Radius

    (mm)

    electrically conductive

    Weight

    (kg)

    		Minimum order quantity
    50
    18
    40
    70
    -
    none
    0.12
    1 pieces
    75
    25
    60
    101
    63.5
    -
    0.17
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    7.57 €
    ( 9.01 € )
    5 working days
    11.33 €
    ( 13.48 € )
    5 working days
  • 1

    • More Information

    Basic information

    [Specifications]
    ・Rolls and case type: Steering housing
    ・Housing classification: Stainless steel apparatus castors AV
    ・Rim material: Polyamide
    ・Tread material: Plastic
    ・Tread color: Black
    ・Wheel diameter(mm): 50, 75
    ・Wheel width(mm): 18, 25
    ・Load capacity dynamic(kg): 40, 60

    This wheel series is shatterproof under high loads and is characterized by its long service life.
    Polyamide can absorb and release moisture and has a high chemical resistance.

    [Features]
    Wheel series PAA:
    ・Wheel body made of polyamide black with plain bearing.
    Housing series AV:
    ・lightweight stainless steel housing with 2-fold ball bearing in the clevis head.
    ・All housing parts, including the axle bolt, are made of rust-resistant materials.
