Apparatus Castors as a set / Steering housing / Mounting plate / Bearing / Steel galvanized / Grey
[Specifications]
・Rolls and case type: Steering housing
・Mounting type: Mounting plate
・Wheel bearing: Bearing
・Housing material RR: Steel galvanized
・Rim material: Polypropylene
・Tread material: Thermoplastic
・Tread color: Grey
[Features]
・castor series AL, thermoplastic, plain bearing:
・lightweight, pressed steel sheet housing, galvanized
・fork head with double ball bearing
・wheels with thermoplastic tires and plain bearings
・(old designation: 1330)
・Rolls and case type: Steering housing
・Mounting type: Mounting plate
・Wheel bearing: Bearing
・Housing material RR: Steel galvanized
・Rim material: Polypropylene
・Tread material: Thermoplastic
・Tread color: Grey
[Features]
・castor series AL, thermoplastic, plain bearing:
・lightweight, pressed steel sheet housing, galvanized
・fork head with double ball bearing
・wheels with thermoplastic tires and plain bearings
・(old designation: 1330)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| L-AL-TPGK-050-G-3-VE4 |
| L-AL-TPGK-075-G-3-VE4 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Plate length (mm) | Plate width (mm) | Wheel diameter (mm) | Wheel width (mm) | Load capacity dynamic (kg) | overall height (mm) | Weight (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
8.82 € | 1 | 5 Days | 55 | 55 | 50 | 18 | 120 | 71 | 0.68 | ||
11.65 € | 1 | 5 Days | 60 | 60 | 75 | 25 | 150 | 101 | 0.9 |
Loading...
Basic information
| Rolls and case type | Steering housing | Mounting type | Mounting plate | Wheel bearing | Bearing |
|---|---|---|---|---|---|
| Housing Series Type | AL (1330/1335/1340/1345/1350/1355 ) | Bolt Hole Length(mm) | 46 | Housing material RR | Steel galvanized |
| Bolt hole width(mm) | 46 | Hole picture apparatus rolls(mm) | 38x38 to 46x46 | Material Description Housing | Lightweight, pressed sheet steel housing, galvanized |
| Surface coating | galvanized | Screw hole(mm) | 6.2 | Number of wheels [piece] | 1 |
| Clevis bearing type | Clevis with double ball bearing | Clevis connection | riveted | Rim material | Polypropylene |
| Tread material | Thermoplastic | electrically conductive | none | Housing design | drawn |
| Tread color | Grey |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
