Apparatus swivel Castors with polyamide wheel
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
L-AL-PAA-075-G-1
- Product data
- CAD data not available
Basic information
| Load capacity dynamic(kg) | 50 | overall height(mm) | 101 | Discharge swivel castor(mm) | 25 |
|---|---|---|---|---|---|
| Rolls and case type | Steering housing | Mounting type | Baack hole | Wheel bearing | Bearing |
| Housing material RR | Steel galvanized | Bolt hole Ø(mm) | 10.2 | Rim material | Polyamide |
| Tread material | Polyamide | Swivel Radius(mm) | 62.5 | electrically conductive | none |
| Housing design | drawn | Housing classification | Apparatus rolls easily AL | Min. temperature resistance(° C) | -20 |
| Max. temperature resistance(° C) | 80 | Weight(kg) | 0.21 |
This page is Apparatus swivel Castors with polyamide wheel, part number L-AL-PAA-075-G-1.
You can find the detail information about specifications and dimensions on part number L-AL-PAA-075-G-1.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
