Manifold subbase with 90° connections, NAVW Series
[Specifications]
・Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
・Ports on the side and on top
・Material of sub-base: Die-cast aluminium, Anodised aluminum
・Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
・Ports on the side and on top
・Material of sub-base: Die-cast aluminium, Anodised aluminum
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
NAVW-1/4-1-ISO
- Product data
- CAD data not available
Basic information
| Material of sub-base | Die-cast aluminum | Pilot air port 12/14 | G1/8 | Pneumatic connection 2 | G1/4 |
|---|---|---|---|---|---|
| Pneumatic connection 4 | G1/4 | Pneumatic connection 1 | G1/4 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Weight(g) | 320 | Manufacturer part # | 152789 |
This page is Manifold subbase with 90° connections, NAVW Series, part number NAVW-1/4-1-ISO.
You can find the detail information about specifications and dimensions on part number NAVW-1/4-1-ISO.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
