Trunnion support, LNZG Series
Click on this image to zoom in.
Click on this image to zoom in.
[Specifications]
・Based on standard: ISO 15552
・Corrosion resistance class CRC: 2 - Moderate corrosion stress
・LABS (PWIS) conformity: VDMA24364-B2-L
・Suitability for the production of Li-ion batteries: Metals with more than 1% by mass of copper, zinc or nickel by mass are excluded from use. Exceptions are nickel in steel, chemically nickelplated surfaces, printed circuit boards, cables, electrical plug connectors and coils
・Ambient temperature: -40°℃...80℃
・Product weight: 129 g
・Note on materials: RoHS-compliant
・Material mounting: Wrought aluminium alloy
・Material bearing: Polymer
・Based on standard: ISO 15552
・Corrosion resistance class CRC: 2 - Moderate corrosion stress
・LABS (PWIS) conformity: VDMA24364-B2-L
・Suitability for the production of Li-ion batteries: Metals with more than 1% by mass of copper, zinc or nickel by mass are excluded from use. Exceptions are nickel in steel, chemically nickelplated surfaces, printed circuit boards, cables, electrical plug connectors and coils
・Ambient temperature: -40°℃...80℃
・Product weight: 129 g
・Note on materials: RoHS-compliant
・Material mounting: Wrought aluminium alloy
・Material bearing: Polymer
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| LNZG-40/50 |
| LNZG-63/80 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Size | Manufacturer part # | Weight (g) | |
|---|---|---|---|---|---|---|---|---|
53.00 € | 1 | 3 Days | 40/50 | 32960 | 129 | |||
60.94 € | 1 | 3 Days | 63/80 | 32961 | 178 |
Loading...
Basic information
| Mounting material | Wrought aluminum alloy | Min. Ambient temperature(°C) | -40 | Max. Ambient temperature(°C) | 80 |
|---|---|---|---|---|---|
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
