Main unit
- Volume Discount
[Specifications]
・Product type: Main unit
・Product size (width)(mm): 30
・Product size (height)(mm): 215
・Product size (depth)(mm): 75
・Nominal voltage(V): 500
Main unit
・Product type: Main unit
・Product size (width)(mm): 30
・Product size (height)(mm): 215
・Product size (depth)(mm): 75
・Nominal voltage(V): 500
Main unit
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 3RK19080AP000AP0 |
| 3RK19080AP000BP0 |
| 3RK19080AP000CP0 |
| 3RK19080AP000DP0 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Manufacturer part # | Type (manufacturer type) | |
|---|---|---|---|---|---|---|
158.49 € | 1 | 11 Days | 3RK19080AP000AP0 | 3RK 1908-0 AP00-0AP0 | ||
141.61 € | 1 | Available | 11 Days | 3RK19080AP000BP0 | 3RK 1908-0 AP00-0BP0 | |
153.03 € | 1 | Available | 11 Days | 3RK19080AP000CP0 | 3RK 1908-0 AP00-0CP0 | |
109.79 € | 1 | 11 Days | 3RK19080AP000DP0 | 3RK 1908-0 AP00-0DP0 |
Loading...
Basic information
| Max. temperature(°C) | +60 | Min. temperature(°C) | -25 | Nominal current(A) | 32 |
|---|---|---|---|---|---|
| Nominal voltage(V) | 500 | Product size (height)(mm) | 215 | Product size (depth)(mm) | 75 |
| Product size (width)(mm) | 30 | Product type | Main unit | Type (misc.) | Spring-loaded connection |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
