FESTO

Finger lever valve, TH Series

Finger lever valve, TH Series

Part number:

Still undefined. 3 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    TH-3-1/4-B
    TH-3-M5
    TH-5-1/4-B
    Related

    Valve function

    Housing material

    Standard nominal flow rate

    (l/min)

    Nominal width

    (mm)

    Actuating force

    (N)

    Max. Operating pressure

    (bar)

    Pneumatic connection 1

    Pneumatic connection 2

    Pneumatic connection 3

    Pneumatic connection 4

    Pneumatic connection 5

    Pneumatic working port

    Operating medium

    Manufacturer part #

    Weight

    (g)

    		Minimum order quantity

    Data sheet

    3/2, closed, monostable
    Die-cast aluminum
    600
    7
    10.5
    10
    G1/4
    G1/4
    G1/4
    -
    -
    G1/4
    -
    8983
    210
    1 pieces

    Data sheet

    3/2, closed, monostable
    Die-cast zinc
    80
    2
    8
    8
    M5
    M5
    -
    -
    -
    M5
    Compressed air as per ISO 8573-1:2010 [-:-:-]
    6758
    37
    1 pieces

    Data sheet

    5/2, monostable
    Die-cast aluminum
    550
    7
    34
    10
    G1/4
    G1/4
    G1/4
    G1/4
    G1/4
    G1/4
    -
    8994
    320
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    158.23 €
    ( 188.29 € )
    7 working days
    77.66 €
    ( 92.42 € )
    7 working days
    217.14 €
    ( 258.40 € )
    7 working days
  • 1

    • More Information

    Basic information

    [Specifications]
    ・Seals material: NBR
    ・Min. Operating pressure(bar): -0.95

    3/2-way valve, monostable
    Reset via mechanical spring
