Tapered roller bearings X Series / Single Track / Sheet steel cage / Class 0
[Specifications]
・I.D. d(mm): 100
・O.D. D(mm): 150
・Width B(mm): 32
・Weight(g): 1910.0
・Precision (JIS): Class 0
・Arrangement: Standard version
・Cage: Sheet steel cage
・Product range: Complete tapered roller bearing
・I.D. d(mm): 100
・O.D. D(mm): 150
・Width B(mm): 32
・Weight(g): 1910.0
・Precision (JIS): Class 0
・Arrangement: Standard version
・Cage: Sheet steel cage
・Product range: Complete tapered roller bearing
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
32020 X
- Product data
- CAD data not available
Basic information
| I.D. d(mm) | 100 | O.D. D(mm) | 150 | Width B(mm) | 32 |
|---|---|---|---|---|---|
| Precision (JIS) | Class 0 | Number of Raceway Ring Rows | Single Track | Arrangement | Standard version |
| Cage | Sheet steel cage | EAN | 0053893252711 | Product range | Complete tapered roller bearing |
| Temperature range | -30 to +120 °C | Weight(g) | 1910.0 |
This page is Tapered roller bearings X Series / Single Track / Sheet steel cage / Class 0, part number 32020 X.
You can find the detail information about specifications and dimensions on part number 32020 X.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
