Angular contact ball bearings / single row / 73xx / internal clearance / BECBMP / NKE BEARINGS
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 7304 BECBMP |
| 7309 BECBMP |
| 7316 BECBMP |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. D (φ) | Outer Diameter D (φ) | Width B (mm) | EAN | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|
39.78 € | 1 | 4 Days | 20 | 52 | 15 | 9008745201677 | 150.0 | ||
100.05 € | 1 | 4 Days | 45 | 100 | 25 | 9008745202063 | 930.0 | ||
293.47 € | 1 | 4 Days | 80 | 170 | 39 | 9008745202629 | 4170.0 |
Loading...
Basic information
| Materials of Inner and Outer Ring | Steel | Accuracy (JIS) | Grade 0 | Number of Bearing Ring Rows | Single Row |
|---|---|---|---|---|---|
| Rolling Element Material | Steel | Cage | Brass cage | Clearance | Normal radial clearance |
| Seal | None open bearing | Temperature range | -20 to +150 degrees | Arrangement | Bearing pair with low axial clearance in O- & X-arrangement |
| Contact angle | 40 degrees |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
