Tapered roller bearings QCL7C Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| LM503349/310 QCL7C |
| T7FC055 QCL7C |
| T7FC060 QCL7C |
| T7FC070 QCL7C |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. d (mm) | O.D. D (mm) | Width B (mm) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|
32.25 € | 1 | 17 Days | 46 | 75 | 18.95 | 300.0 | ||
- | 1 | Quote | 55 | 115 | 34 | 1580.0 | ||
140.13 € | 1 | 4 Days | 60 | 125 | 37 | 2070.0 | ||
- | 1 | Quote | 70 | 140 | 39 | 2568.0 |
Loading...
Basic information
| Precision (JIS) | Grade 0 | Number of Raceway Ring Rows | Single Row | Arrangement | Standard version |
|---|---|---|---|---|---|
| Cage | Sheet steel cage | Product range | Complete tapered roller bearing | Temperature range | -30 to +120 °C |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
